Help CenterNexo PS15, 15 Inch 15 Inch Passive 2-way Full Range Loudspeaker, Stage Monitors
Related Products
-
Nexo PS15+, 600Watts, 15 Inch Passive 2-way Full Range Loudspeaker, Professional Speakers Quality ChoiceUS$ 299 - 329MOQ: 10 Pieces -
PS-15TT+, Trade Assurance, Neodymium Speaker, 15 Inch Passive 2-way Full Range LoudspeakerNegotiableMOQ: 10 Pieces
-
PS-15BASS, Trade Assurance, 15 Inch Bass Loudspeaker, Professional LoudspekerUS$ 250 - 300MOQ: 4 Pieces
-
LS-500, Trade Assurance, 15 Inch Passive Subwoofer, Speakers SubwooferUS$ 249 - 279MOQ: 4 Pieces
-
LS1200, Trade Assurance, 18 Inch Passive Subwoofer, Speakers SubwooferUS$ 225 - 255MOQ: 4 Pieces
[ Factory, EXW price, quickly shipment, alibaba trade assurance, 10 years of OEM ]:
PS15 loudspeaker descriptions:
1. PS15 is a versatile , 2-way passive system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure.
2. It features a powerful 15''(375mm) low frequency driver and a 1.5''(37mm) HF compression driver mounted on a constant directivity 90° x 50° horn.
3. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.
PS15 loudspeaker features:
1.Versatile, passive 2-way full range system, 1x15''LF + 1x3''HF, 400W - 800W.
2. Full sound, powerful bass, low distortion, pure and natural tone quality, light wight, easy to install and safely.
3. Best chioce for nightclubs, bars, Disco, theaters, church, concert halls, Band, stage performance, wedding, touring performance, etc.
4. This model is outstanding used in the slow rock bars, which displys very full voices, and the bass is powerful.
PS15 loudspeaker specifications:
| Frequency Response[a] | 58Hz-18kHz±3dB |
| Usable Range@-6dB [a] | 55 Hz-20kHz |
| Sensitivity 1W@1m[b] | 98dB/w/m |
| Nominal Peak SRL@1m[b] | 120dB to 126dB Peak (for 400 to 800W RMS Amp.) |
| HF Dispersion[c] | 50°to 100°Hor. × 55°Vert. Rotatable Horn |
| Rated power | 400W RMS, 800W peak into 8Ω |
| Norminal impedance | Passive: 8Ω; Active: LF 6.5Ω, HF 8Ω. |
| Components |
LF: 1×15″(380mm) Shielded 6.5 Ω driver, Ferrite HF: voice coil HF driver size 3''(72mm) Constant Directivity Asymmetrical Dispersion Horn |
| Install Dim(HxWxD) | 675x434x369mm |
| Weight | 28kg |
| Connectors | 3×NL4MP 4-pole SPEAKON |
PS15 loudspeaker box design:
PS15 loudspeaker driver configuration:
HF:
LF:
♥ OEM /ODM orders are warmly welcome ,we can make the varied designs according to your need. Besides, we service alibaba trade assurance.
♥ All the goods are inspected before shipment, so we can ensure the best quality of products .
♥Free warranty service for one year ,within this period ,you can enjoy free maintenance service by warranty cards and invoice if a failure occurs under normal operation.
♥ If you have any problems,please feel free to let us know, by e-mail, telephone ,skype, WhatsApp or the others ,we will reply you as soon as we can.
