SUNBOW 22.0 mm orange heat shrink tube for Charging pile
- 1000000 Meter / Meters per Month
- shenzhen
- Credit Card
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- High Viscosity 3W/MK Thermally Conductive Putty For BGA Package
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
Product Details
Place of Origin: | Guangdong, China | Brand Name: | SUNBOW | Model Number: | SB-RSFR-125H |
Type: | Insulation Sleeving | Material: | PE | Application: | Low Voltage |
Rated Voltage: | 300V/600V | Tensile Strength: | 10.4MPA |
Product Description
GRADE:SB-RSFR-125H
Operating temperature:-45°C~125°c
STRUCTURE
Halogen free heat shrinkable tube is developed environment-friendly flame retardant heat shrinkable tube,
using specially designed formulation of high polymers, through cross-link by electronic accelerator and
continuous expansion. It performs environment-friendly, flexible flame retardant, quick shrink and stable
characteristics. It has passed 600V/300V certificate.
USAGE
1. Usage: electrical insulation, welding point anti-corrosion, mechanical protection
2. Application range:Electronics, communication, automobiles, shipping and other manufacturing range.
ELECTRICAL PERFORMANCE
Property | Unit | Test Method | Standard | |
Tensile strength | MPa | ≥10.4(before aging) | GB/T 1040 | |
≥7.3(after aging) | 158°C×168h | |||
Breakage elongation (%) | % | ≥200(before aging) | GB/T 1040 | |
≥100(after aging) | 158°C×168h | |||
Heat shock | - | No sticking, no cracking | 250°C×4h | |
Cold blend | - | No cracking | -30°C×4h | |
Breakdown strength | kv/mm | ≥15 | GB/T 1408 | |
Dielectric withstand | 600V | - | Pass | No breakdown for 2500V,60s |
300V | - | Pass | No breakdown for 1500V,60s | |
Volume resistivity | Ω.cm | ≥1×1014 | GB/T 1410 | |
Corrosion performance | - | Pass | 158°C×168h | |
Copper stability | - | Pass | 158°C×168h | |
Flammability | - | Pass | VW-1 |
DIMENSION
Halogen free flame-retardant normal wall heat shrinkable tube
Halogen free flame-retardant thin wall heat shrinkable tube
1) 3~5 quick time production;
2) 2 years quality guarantee;
3) Prompt feedback;
4) 24 hours on line servic.
5) Free sample for your approval
1. What is the MOQ?
1000 meters.
2. What is the payment terms?
T/T 100% in advance or Western Union
