Help CenterSUNBOW 22mm Orange Color Polyolefin Heat Shrink Tube for New Energy Vehicles
Related Products
-
SUNBOW 2:1 Shrink Ratio Clear 6mm Heat Shrink Tubing for FlashlightUS$ 0.01 - 22.22MOQ: 3000 Meters -
SUNBOW 6mm Clear Polyolefin Heat Shrink Tube for Children's ShoesUS$ 0.01 - 22.22MOQ: 3000 Meters
-
Environment Friendly Adhesive-lined Dual Wall Heat Shirnkable Tube(3:1,4:1)US$ 0.25 - 9.45MOQ: 1000 Meters
-
Environment Friendly Adhesive-lined Dual Wall Heat Shirnkable Tube(3:1)US$ 0.25 - 9.45MOQ: 1000 Meters
-
Environment Friendly Dual Wall Electric Heat Shirnkable Tube(2:1)US$ 0.25 - 9.45MOQ: 1000 Meters
GRADE:SB-RSFR-125H
Operating temperature:-45°C~125°c
STRUCTURE
Halogen free heat shrinkable tube is developed environment-friendly flame retardant heat shrinkable tube,
using specially designed formulation of high polymers, through cross-link by electronic accelerator and
continuous expansion. It performs environment-friendly, flexible flame retardant, quick shrink and stable
characteristics. It has passed 600V/300V certificate.
USAGE
1. Usage: electrical insulation, welding point anti-corrosion, mechanical protection
2. Application range:Electronics, communication, automobiles, shipping and other manufacturing range.
ELECTRICAL PERFORMANCE
Property |
Unit |
Test Method |
Standard |
|
Tensile strength |
MPa |
≥10.4(before aging) |
GB/T 1040 |
|
≥7.3(after aging) |
158°C×168h |
|||
Breakage elongation (%) |
% |
≥200(before aging) |
GB/T 1040 |
|
≥100(after aging) |
158°C×168h |
|||
Heat shock |
- |
No sticking, no cracking |
250°C×4h |
|
Cold blend |
- |
No cracking |
-30°C×4h |
|
Breakdown strength |
kv/mm |
≥15 |
GB/T 1408 |
|
Dielectric withstand |
600V |
- |
Pass |
No breakdown for 2500V,60s |
300V |
- |
Pass |
No breakdown for 1500V,60s |
|
Volume resistivity |
Ω.cm |
≥1×1014 |
GB/T 1410 |
|
Corrosion performance |
- |
Pass |
158°C×168h |
|
Copper stability |
- |
Pass |
158°C×168h |
|
Flammability |
- |
Pass |
VW-1 |
|
DIMENSION
Halogen free flame-retardant normal wall heat shrinkable tube
Halogen free flame-retardant thin wall heat shrinkable tube
1) 3~5 quick time production;
2) 2 years quality guarantee;
3) Prompt feedback;
4) 24 hours on line servic.
5) Free sample for your approval
1. What is the MOQ?
1000 meters.
2. What is the payment terms?
T/T 100% in advance or Western Union
SUNBOW 22mm orange color polyolefin heat shrink tube for New energy vehicles
