Help CenterFP10000Q 4channel High Power Amplifier
Related Products
-
MEGA LP-5, Tade Asurance, 2 Chnnel Power Amplifier, Professional AmplifierUS$ 379 - 399MOQ: 10 Pieces -
LP-3, 500 Watt Amplifier, 2 Channel Power Amplifier, Professional AmplifierUS$ 315 - 345MOQ: 2 Pieces
-
LP-2, Trade Assurance, 2channel Power AmplifierUS$ 279 - 299MOQ: 2 Pieces
-
LP-1, Trade Assurance, 2 Channel Power Amplifier, 300 Watt AmplifierNegotiableMOQ: 4 Pieces
-
FP7000Q , Trade Assurance, 2channel Power Amplifier, Professional AmplifierNegotiableMOQ: 2 Pieces
More power from smaller and lighter racks, with more configuration flexibility, and yet with no compromise in the legendary Lab-gruppen sound - that's the promise fulfilled by FP+ series amplifiers.
The expanded FP+ series with both two- and four- channel versions spread across a range of power output levels. The flagship FP14000 produces staggering output power of 14000Q (from a 2U chassis weighing only 12kg), making it ideal for powering larger subwoofers. Other FP+ series models offer power levels and channel conofigurations scaled to match every conceivable touring application, from band-limited line array drivers to full-range monitor and fill loudspeakers.
To achieve the extraordinary power-to-size ratio in the FP+ series, Lab-gruppen engineers refined and upgraded two proprietary technologies. The regulated Swith Mode Power Supply (R.SMPS) and the patented Class TD output stage. Working together, these new-geeneration proprietary circuits produce more power from a smaller package while maintaining Lab-gruppen's peerless reputation for sonic excellence. The highs stay crisp and transparent. The mids are warm and natural. And the tight lowend delivers visceral impact.
Information, control, reassurance.
All FP+ series amplifiers offer real-time monitoring and control cia the NomadLink network with network modules built in as standard equipment. Finally, standing behind Lab-gruppen's reputation for rock-solid reliabilty is a six-year, no-quibble warrany.
FP10000Q & FP7000Q power amplifier specifications:
Specifications | ||
power amplifier | ||
Model |
FP7000Q |
FP10000Q |
Output Power |
20-20kHz, 1W with 1 khz |
|
8ΩStereo Power(RMS) |
1450WX2 |
1300WX4 |
4ΩStereo Power(RMS) |
2800WX2 |
2100WX4 |
2ΩStereo Power(RMS) |
3500WX2 |
2500WX4 |
8ΩBridged Power(RMS) |
5600W |
|
4ΩBridged Power(RMS) |
8000W |
|
Frequency Response(+o/-0.3dB,1W/8Ω) |
20 Hz - 34 kHz |
|
THD 20 Hz - 20 kHz for 1 W |
<0.1% |
|
Signal-to-Noise Ratio |
>112 dBA |
|
Channel separation (Crosstalk) at 1 kHz |
>70 dB |
|
Input Connectors (per channel) |
3-pin XLR, electronically balanced |
|
Output Connectors (per channel) |
Binding Posts 2-pole |
|
Class |
TD |
|
TourClass Protection |
ACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input |
|
Operating voltage, 230 V / 115 V nominal |
130-265 V / 65-135 V selectable |
|
Voltage Gain(dB) |
23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
|
Input impedance |
20 kOhm |
|
Level adjustment (per ch.) |
Front-panel potentiometer, 31 position detented from -inf to 0 dB |
|
Dimensions (W×H×D) |
483×88×396mm |
|
Packing dimension |
560×180×500mm |
|
Net weight |
15KG |
|
Gross weight |
18KG |
|
