1. M100MKII is a line array loudspeaker for long throw distance sound reinforcement.
2. Using the M100MKII Flying Frame it can be flown in vertical columns with up to 16 cabinets.
3. M100MKII is a four-way design housing fitted with two 10"LF drivers, two 6.5"MF drivers and two 1.7" drivers.
4. The cylindrical wave segments of each cabinet can couple without gaps coherently andgles between adjacent cabinets can be set in the range from 0° to 5°.
M100MKII line array speaker features:
♣ A doubel 10" passive line array speaker, 750-1500watts, with two 10" LF, two 6.5" MF and two 1.7" HF drivers.
♣ Strong penetrating, high fidelity and low distortion, clear, pure and natural tone quality.
♣ With multilayer plywood, environmental textured black painting, newest humanzied design, simple and esay for rigging.
♣ Widely used in AV application system, touring, stage, outdoor&indoor performance ect.
M100MKII line array speaker specifications:
| Type: | Compact, Four-way passive |
| Frequency Response(-10dB): | 65Hz-19kHz |
| Frequency Response(-3dB): | 70Hz-19kHz |
| System Input Power Rating: | 750W Continuous 1500W Peak |
| Max Calculated SPL: | 128dB Cont 134dB Peak |
| Horizontal Coverage: | ≥75° |
| Vertical Coverage: | Vertical coverage angle change according to the different quantity configuration. |
| LF Power Handing: | 2X250W Cont, 1000W Peak |
| MF Power Handing: | 2X120W Cont, 480W Peak |
| HF Power Handing: | 2X45W Cont, 180W Peak |
| Sensitivity(LF/MF/HF): | 97/96/106dB |
| LF to MF crossover Freq.: | 300-600Hz |
| MF to HF crossover Freq.: | 1700Hz Passive or Active |
| LF Passband: | 2x10" Ferrite, 8ohms/pcs |
| MF Passband: | 2x6.5" Ferrite, 16ohms/pcs |
| HF Passband: | 2x1.7" Neodymium, 16ohms/pcs |
| Connectors: | Neutrik: 2*EP8 |
| Install Dim: | (H)300X(W)445X(D)1002mm |
| Net Weight: | 43kg |
| Range Inputs: | ±1: LF(1) ±2: LF(2) ±3: MF ±4: HF |
♦ Our factory supports Alibaba Trade Assurance, 100% product quality protection.
♦ OEM or ODM orders are warmly welcomed, we could produce varies speakers according to your drawings.
♦ Offer 1year free warranty, except the man-made damaged.
♦ All the products will be tested and inspected before the delivery.
