Help CenterShrinkless Tube Expander Expanding Machine
Related Products
OMS shrinkless expander is such an expander that both tube ends are secured before expanding. The design saves copper tube by 2.5%-3% and power consumption by 50%.
It is a patented design of OMS, and has been highly regarded by our customers because of its help in reducing production cost. In 2011, it was accredited as “High Technology Product” by Chinese government.
If you are looking for cost savings, OMS shrinkless expander will be a great choice.
Features:
1. Tube expanding, end flaring and flanging are done in one process.
2. Shrinless expanding. Save tubes and energy.
3. Expanding rods can be secured quickly. A protection mechanism prevents damage to the expanding rod.
4. Highly automated, which reduces labor intensity.
5. The machine can run for 24 hours each day with sound performance. Its low failure rate allows for mass production.
6. The design takes ergonomics into consideration. The machine is easy to operate, requiring only low maintenance. The noise level is low.
7. In the case of failure, the control panel screen will display causes and provide solutions, to enhance efficiency.
Technical specification:
| No. | Item | Content | Remarks | |||||
| 1 | Copper O.D. and W.T | φ7.94X0.29 |
|
|||||
| 2 | Processing(hairpin) length | Min:300mm Max:1200mm | ||||||
| 3 | Pattern type | 47*3 | ||||||
| 4 | Hole pitch * Row pitch | 25.4mm*19.05mm | ||||||
| 5 | Nozzle height (A) | 11mm | ||||||
| 6 | Collar height(B) | 1.5mm | ||||||
| 7 | Flaring length(C) | 6mm | ||||||
| 8 | Base height (L) | 19mm | ||||||
| 9 | Collar angle | 60° | ||||||
| 10 | Bullet diameter | φ7.78mm | ||||||
| 11 | Flaring diameter(D2) | φ8.16 | ||||||
| 12 | Upper clapboard height(H1) | 45mm | ||||||
| 13 | Down clapboard height(H2) | 100mm | ||||||
| 14 | Upper clapboard pitch(U) | 10mm | ||||||
| 15 | Down clapboard pitch(V) | 20mm | ||||||
| 16 | Max number of tube expanded simultaneously | 110 | ||||||
| 17 | Expanding mode | Shrinkless | ||||||
| 18 | Expander main motor | A C servo mtor 7KW | ||||||
| 19 | Transmission mode of expansion tube | Ball leading screw | ||||||
| 20 | Height control of expansion tube | Servo motor 1KW | ||||||
| 21 | double-position worktable turning | Servo motor 1KW | ||||||
| 22 | Flaring height control of two to three times | Servo motor | ||||||
| 23 | Flaring power of two to three times | Servo motor | ||||||
| 24 | Flaring mode of two or three times | Scanning mode flaring | ||||||
| 25 | Efficiency | 30seconds /times (L=1000mm)Inlcuding 15 seconds for loading and unloading coil | ||||||
| 26 | Electric cabinent cooling | Cabinents Air conditioner | ||||||
| 27 | Compressed air pressure | 0.4-0.6Mpa | ||||||
| 28 | Hydraulic system pressure | 7Mpa | ||||||
| 29 | locking force of upper collet | Hydraulic system | ||||||
| 30 | hydraulic motor power | 3.75KW | ||||||
| 31 | Cooling mode of hydraulic system | wind cooling | ||||||
| 32 | Overall size | 1750mm*2902mm*5205mm | ||||||
| 33 | Total power | ≤15KW | ||||||
| 34 | Power supply | Three-phase AC 415 V±5%(Three-phase, Four-wire) 50Hz | ||||||
