Specifications
1.CCD Camera Laser Cutter Machine2.DSP control system
3.Automatic image positioning
4.High speed, high accuracy
CCD Camera Laser Cutter Machine (GLS1080V) and CE&SGS
Product Features
1) Glorystar has committed to new product innovation and development, hereby makes one automatically intelligent models, which adopts Panosonic 6.40 M CCD camera to automatically cut the products outline. This camera laser cutting machine can cut efficiently and perfectly the abnormal woven or printing trademarks. This series laser machines use the best quality parts to ensure the cutting precision.
2) This series laser cutting machines adopts DSP controlling System, 128M saving stock, stepping motor imported from Germany, 6.40M CCD industrial camera, Industrial Water cooling system, six-balanced straight line guide originally imported from Japan, 70W CO2 laser made in China. anti-jam industrial computer, image catching software and precise high resolution optical meter, 2.0USB data transferring, LCD panel.
Applicable Industry
Widely applied in computerized woven labels, irregular embroidery badges and embroideries crafts for fine and precise positioning cutting.
Product Data
| Model | GLS-1080V |
| Laser type | glass CO2 laser tube |
| Laser power | 60-80W |
| Engraving area | 1000x800mm |
| Engraving speed | 0-64m/min |
| Cutting spees | 0-36m/min |
| Repeating lacating | ±0.05mm |
| Moving system | CNC control system |
| CCD reslolution ratio | 6.40M pixels |
| Cooling mode | Water-cooling and protection system |
| Whole power | ≤1250w |
| Working voltage | 220±10% 50Hz(60Hz) |
| Operating temperature | 0~45ºC |
| Prerating humidity | 5%-95% |
| Controlling sofeware | Glorystar laser software |
| Graphic format supported | CAD BMP,JPG,PNG,TIF,PCX,TAG,IOO,GIF,PLT |
| Gross weight | 490KG |
Applicable Materials
Paper, leather, cloth, organic, glass, resin, acrylic, wollens, plastic, rubber and other non-metal materials.
