Specifications
automatic blow molding machine:1. ours is a manufacture company
2. fast-speed
3. simple operation
4. save energy
automatic blow molding machine:
Parameter | Wsj-5(1) | Wsj-5(2) |
Single die head | Double die head | |
Max volume of product L | 2.5 | 1 |
Circulation without material time / hr | 700×2 | 700×4 |
Diameter of screw mm | 55 / 65 | 55 / 65 |
ratio of L/D of screw L / D | 25: 1 | 25 : 1 |
Motor power for screw kw | 7.5 / 15 | 7.5 /15 |
Heating section of screw ZONE | 3 - 4 | 3 - 4 |
Quantity of extrusion(PE) kg / hr | 40 / 60 | 40 / 60 |
Journey of opening and closing of mould mm | 160 | 160 |
Max dimension of mould mm | 160×240×280 | 160×240×280 |
Distance of the centers of the double mould head mm | ____ ____ | 120 |
Pressure of gas blowing Mpa | 0.6 | 0.6 |
Gas consumption m3 / min | 0.8 | 0.8 |
Appearance dimension of machine mm | 2500×1500×1700 | 2500×1500×1700 |
Weight of machine kg | 1500 | 1700 |
Method of adjusting the speed | Frequency conversion | |
Method of control | PLC computer control | |
