Computer Controlled Horizontal Type Blow Mold Machine

Computer Controlled Horizontal Type Blow Mold Machine photo-1
US$ 10,000 - 13,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Bottle
Plastic Processed PE
Blow Moulding Type Extrusion Blow Moulding
Automatic Yes
Place of Origin Hebei, China
Brand Name zhongyi
Model Number wsj-6
Voltage 380V
Power(W) 16KW
Dimension(L*W*H) 3100*1400*1600mm
Weight 900KG
Certification patent
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

computer controlled horizontal type blow mold machine
ours is a manufacture
exquisite design
positioning accurate
reliable

computer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machinecomputer controlled horizontal type blow mold machineHorizontal computer controlled horizontal type blow mold machine:

Type

WSJ-5

WSJ-6

WSJ-7

The max volume of the product L

1.5

4

6

The quantity of the die head

1/2/3/4

The quantity of the moulds(set)

2

Production capacity(without material)pcs/h

1500

1200

1000

Screw diameter mm

55

55

65

Long radius rate L/D

1:25

1:25

1:25

The max plasticizing capacity of HDPE kg/h

40

40

55

Clamping method

pneumatic/hydraulic

The mothed of cutting the pipe of material

Hot cutting knife

Journey of opening and closing of mould mm

160-360

200-430

230-480

The max dimension of the mould(T×W×H)mm

160×210×300

200×270×350

230×310×400

The adjustment range of the thickness of the mould mm

120-160

160-200

190-230

Blowing pressure Mpa

0.4-0.6

0.4-0.6

0.5-0.7

The electric machinery power of extruder machine KW

7.5

7.5

11

The heating power of extruder machine KW

8.5

8.5

10.5

Appearance dimension mm(LXWXH)

3100×1400×1600

3300×1650×1700

3400×1750×1700

Total weight kg

900

1100

1200

Method of control

PLC computer control

The suitable raw material

PE/PP/PS/PVC
