40T Crawler Hydraulic Excavator

Name: 40T Crawler Hydraulic Excavator
Brand: heking
SKU: 100551267
Availability: InStock

US$ 230,000 - 320,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

China

Brand Name:

heking

Model Number:

HK400

Anhui Hekuang Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name heking

Model Number HK400

Specifications

1. Original imported Cummins engine
2.Original imported hydraulic components
3.High strength,stability for mines and quarries

Type	HK400
Operting weight(t)	40
Bucket capacity(m3)	1.8
Engine model	isuzu
Engine power(kw/rpm)	235kw/1800rpm
Volume of fuel tank(L)	650
Walking speed(km/h)	5.2/3.3
Ratary speed(r)	10.6
Climbing capapcity(%)	70
Bucket digging force(kN)	208
Ground pressure(kPa)	67.6
Hydraulic pump model	T5V180DP
Max.flow(L/min)	316*2
Working pressure(Mpa)	34.3
Volume of hydraulic oil tank	350
Overall length(mm)	11080
Overall width(mm)	2995
Overall height(to top of boom)(mm)	3180
Overall height(to top of cab)(mm)	3280
Counterweight ground clearance(mm)	1210
Min.ground clearance(mm)	498
Rear swing radius(mm)	3420
Length of track on ground(mm)	3700
Track width(mm)	4622
Track gauge(mm)	2590
Track width(mm)	3190
Track shoe width(mm)	600
Turntable width(mm)	2995
Max.digging height(mm)	10200
Max.dumping height(mm)	7135
Max.digging depth(mm)	7370
Max.vertical digging depth(mm)	6380
Max.digging distance(mm)	11100
Max.digging distance on horizontal plane(mm)	10910
Min.swing radius(mm)	4265
Max.height at min. swing radius(mm)	8500
Distance between gyration center and backend(mm)	3420
Track shoe thickness(mm)	30
Counter weight height(mm)	2265
Length of track on ground(during transportation)	5720
Arm length(mm)	3185
Boom length(mm)	6470
