CE L3.5T-5.0T Four-pivot Battery Forklift Truck-CPD35-50

CE L3.5T-5.0T Four-pivot Battery Forklift Truck-CPD35-50 thumbnail-1
CE L3.5T-5.0T Four-pivot Battery Forklift Truck-CPD35-50 thumbnail-2
CE L3.5T-5.0T Four-pivot Battery Forklift Truck-CPD35-50 photo-1
CE L3.5T-5.0T Four-pivot Battery Forklift Truck-CPD35-50 photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
cheuklift
Contact Supplier Request Quote Chat Now
Shanghai Cheuk's Logistics Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name cheuklift
Model Number CPD35-50
Type Other, Forklift truck
Power Souce DC Motor
Rated Loading Capacity 2t
Max. Lifting Height 6m
Min. Lifting Height 3m
Fork Length 1070mm
Fork Width 130/150mm
Overall Dimensions 2670/2863x1230/1464x2150/2265mm
Certification CE
After-sales Service Provided No overseas service provided
The basic information of 3.5T-5.0T Four-pivot Battery forklift truck-CPD35-50

Product Intro

Electronic control system by the Italian ZAPI, mature and reliable electronic control system, electrical control installation using fully enclosed structure to ensure the electronic control and hydraulic components from contamination and water splash.
Key vehicle components, from the electronic control, instrumentation to the safety switches are well-known imported brands, key components through a rigorous reliability tests to ensure the stability of overall performance.
Wide view of the door frame design and optimization of the door frame structure, so that a more open view of the operator, operating efficiency and safety can be improved.
Spacious room for maneuver, adjustable steering wheel and seat, the operator can choose the best driving position.
Rational distribution of the control system, fully embodies the principles of ergonomics to improve comfort and reduce operator’s labor intensity.





The specification of 3.5T-5.0T Four-pivot Battery forklift truck-CPD35-50

Specifica
tion		 1.1 Model unit CPD35 CPD40 CPD45 CPD50
1.2 Drive type   ZAPI AC CURTIS DC ZAPI AC
1.3 Capacity kg 3500 3500 4000 4500 5000
1.4 Load centre distance mm 500 500 500 500 500
1.5 Lift height mm 3000 3000 3000 3000 3000
1.6 Free lift mm 170 170 150 150 155
1.7 Fork size(L*W*T) mm 1070*130*50 1070*150*50 1070*150*55
1.8 Mast tilt(forward/backward α°/β°) Deg 6/12 6/12 5/10 5/10 5/10
Dimensions 2.1 Length mm 2670 2670 2863 2863 2863
2.2 Width mm 1230 1230 1464 1464 1464
2.3 Height(mast lowered) mm 2150 2150 2265 2265 2265
2.4 Mast extended height (with safeguard) mm 4100 4100 4220 4220 4220
2.5 Overhead load guard height mm 2150 2150 2350 2350 2350
2.6 Min turning radius mm 2335 2335 2557 2557 2557
2.7 Front overhang mm 505 495 570 570 575
2.8 Tread(F/B) mm 1000/980 1000/980 1240/1050 1240/1050 1240/1050
2.9 Min ground clearance mm 130 130 154 154 154
2.1 wheelbase mm 1680 1680 1800 1800 1800
2.11 Fork adjustable (Max/Min) mm 260/1100 250/1100 300/1380 300/1380 300/1380
2.12 1000×1200 crossways   4090 4090 4402 4402 4402
2.13 800×1200 lengthways mm 4220 4220 4828 4828 4828
Performance 3.1 Travel speed(laden) km/h 12 12 13.5 13.5 13.5
3.2 Travel speed(unladen) km/h 12.5 13 14.5 14.5 14.5
3.3 Up speed(laden) mm/s 250 220 300 290 280
3.4 Down speed(unladen) mm/s 400 384 480 440 420
3.5 Gradeability(laden/unladen) % 15/15 15/15 20/20 20/20 20/20
3.6 N.W(Inc. battery) kg 5380 5380 6642 6912 7212
3.7 Tyre(FrontX2)   28x9-15-12PR 250-15 250-15 250-15
3.8 Tyre(RearX2)   18x9-8-14PR 21x8-9 21x8-9 21x8-9
Drive
motor		 4.1 Travel motor kw 12 10 - - -
4.2 Lift motor kw 7.4 10 - - -
4.3 Travel motor*2 kw - - 11*2 11*2 11*2
