Help CenterMiniature Peristaltic Pump
Related Products
Specifications
miniature peristaltic pumpminiature peristaltic pump
• Variable speed peristaltic pump, simple operation, small size, easy installation, suitable for ancillary equipment and laboratories;
• Small volume manual control variable speed pumps;
• Buttons control the speed, rotating, starting and stopping, full speed, state memory (power-down memory);
• For pump head: DG1, DG2;
• Flow range: 0.00016 ~ 48 ml / min
DG flow range (ml / min) | ||||
tube type |
0.5×0.8 |
2.4×0.8 |
1×1 |
2×1 |
0.1-100 rpm |
0.002~2.1 |
0.026~26 |
0.0058~5.8 |
0.021~21 |
DG import tube flow range (ml/min) | ||||||
tube type |
0.13 |
0.25 |
0.5 |
0.76 |
1 |
1.22 |
0.1-100 rpm |
0.00016~0.16 |
0.0005~0.5 |
0.0022~2.2 |
0.0048~4.8 |
0.0058~5.8 |
0.01~10 |
tube type |
1.52 |
1.65 |
2.1 |
2.4 |
2.79 |
3.17 |
0.1-100 rpm |
0.017~17 |
0.018~18 |
0.021~21 |
0.026~26 |
0.035~35 |
0.048~48 |
Technical parameters
•Speed range: 0.1 ~ 100 rpm
•Speed resolution: 0.1 rpm, with accuracy 0.5%
•Display: 3 LED digital speed display
•External control functions: external control start and stop,external control direction, with isolation,
5V, 12V, 24V optional-level input;
0 ~ 5V/10V, 4 ~ 20mA, 0 ~ 10KHz speed optional;
RS485 bus, support MODBUS communication protocol
• Supply voltage: AC220V ± 10% 50/60HZ (optional DC24V input)
• Consumption ratio: less than 30W
•Working Environment Temperature: 0 ~ 40 °C Relative humidity <80%
• Dimensions: (L × W × H) 223mm × 150mm × 195mm
• Weight: 4.7kg
