High Quality DN100 220V Dc Solenoid Valve
Name:High Quality DN100 220V Dc Solenoid Valve
Model: 2W31-10T
Diameter:DN15-DN50
Medium:Fresh water,sewage,sea water,weak acid,weak base etc.
Temperature:-5-80 degree
Body material:Stainless Steel
Voltage:
DC - 12V,24V AC - 24V,120V, 240V@60HZ 110V, 220V@50HZ Tolerance: +/- 10%
Coils :S51B, 40VA(AC), 30W(DC), IP65 100%ED
SD01B, 35VA(AC),30W(DC),IP65,100%ED
SD02B,flying lead 35VA(AC),30W(DC),IP65,100%ED
Material:
Body - Brass or Stainless steel
Seal -NBR, EPDM, PTFE or VITON
Armature Tube - Stainless Steel 304
Plunger - Stainless Steel 430F
Stop -SS430F
Springs - SS 304
Shading Rings - Stainless Steel 304
Characteristic:
1.Direct lifting diaphragm construction;
2.Open from zero bar for low pressure system use;
3.High frequency of DIN plug coil
4.Medium:Air, City Gas, Water, Oil, Petroleum, etc.
5.Pressure:2W21: 0.00MPa ~ 1.0MPa.
6.Port Thread:BSPP ,BSPT ,NPT ,Flange, UNF, M8X1
Temperature:
NBR Seal: 14F to 176F , -10 to 80
EPDM Seal: 14F to 250F , -10 to 120
VITON Seal : 14F to 300F, -10 to 150.
Port Size:3/8,1/2,3/4,1,1 1/4,1 1/2,2
Orifice (mm): 12,15,20,25,32,40,50
Model |
2W31 |
Characteristic |
1.Direct lifting diaphragm construction |
Working Medium |
?Water, air,city gas,oil,Petroleu etc. |
Type |
Normally closed type |
Operating Temperture |
NBR Seal: 14F to 176F, -10~80°C |
Port Size |
3/8,1/2,3/4,1,1 1/4,1 1/2,2 |
Port Thread |
BSPP,BSPT,NPT,Flange,UNF |
Orifice (mm) |
12,15,20,25 |
Voltage |
DC - 12V,24V |
Tolerance |
-10%~+10% |
Working-pressure |
0~1.0Mpa |
Coils |
?S91B, 17VA(AC), 10W(DC), IP65,100%ED |
Material |
Body:Brass or Stainless steel |
In the 19 years, we have customers in many countries around the world.
1.We promise no leakage and breakage for valves. Every butterfly valve will test for 2 times test pressure before leave factory. We will replace the valve if there is quality problem within 24 months guarantee period.
2.We obtained ISO9001 quality system certification.We inspect the parts of valve carefully, 48 produce steps, try to supply you ideal valve.
3.We can supply different kinds of materials according to customers' requests,such as DI,cast steel,SS304,SS316 body and disc. EPDM,NBR,PTFE,Viton etc. Enough stock ensure fast delivery.
4.We have more than 150 types body moulds, which include ISO,DIN,ANSI,BS standard.
5.We own full-automatic machine paint line, match high-temperature baking house,which makes smooth paint and good appearance of valve.
About Jinerjian
Jinerjan (Tianjin) Valve Co., Ltd. is a manufacturer which is specialized in researching, producing and exporting wafer butterfly valves, flange butterfly valves, electric butterfly valves, pneumatic butterfly valves and dual plate check valves. Through all staff"s efforts, our business has expanded rapidly in the past 18 years. We have set up foundry, machining and assembly workshop
