JEJ brass gate valve 3 inch for brass gate valve
Overview for JEJ brass gate valve 3 inch for brass gate valve
1.Nominal Pressure:1.6MPa
2.Suitable Medium :Water,Saturated Steam,Oil, Ga
s 3.Working Temperature:-20 ~180 degree
4.Thread : ISO 07
5.Solder Socket To ANSI B16/18
6.Size: 1/2" ~ 4"
7.Delivery: In 30 Days
Adoptive Standard for JEJ brass gate valve 3 inch for brass gate valve:
Solder Socket To ANSI B16/18
Features of JEJ brass gate valve 3 inch for brass gate valve
(1)Forged Brass Screw Gate Valve, Brass valve, Brass Gate Valve
(2)Forged body, cast iron handle
(3)Cast Iron Wheel Handle, can be changed to allum. handle
(4)Screw Ended
(5)Material: CW614N, CW617N, C37700 as per request.
(6)Thread: BSP, NPT as per request
(7)Marking: Can marked be as per request.
(8)100% Pressure Tested.
| DN | SIZE | A | B | C | D | G |
| 10 | 3/8 | 42 | 9.5 | 66.5 | 45 | 3/8 |
| 15 | 1/2 | 43 | 12.8 | 71 | 54 | 1/2 |
| 20 | 3/4 | 46 | 17.5 | 77 | 54 | 3/4 |
| 25 | 1 | 53 | 22 | 89 | 60 | 1 |
| 32 | 1 1/4 | 55 | 27 | 101 | 68 | 1 1/4 |
| 40 | 1 1/2 | 58 | 34 | 111 | 72 | 1 1/2 |
| 50 | 2 | 66.5 | 45 | 128 | 80 | 2 |
| 65 | 2 1/2 | 84.6 | 55 | 161 | 100 | 2 1/2 |
| 80 | 3 | 85 | 66 | 187.5 | 110 | 3 |
| 100 | 4 | 105.6 | 87 | 226.7 | 126 | 4 |
Forged Brass Screw Gate Valve, Brass valve, Brass Gate Valve
Thread: BSP, NPT as per request
Forged body, cast iron handle
Cast Iron Wheel Handle, can be changed to allum. handle
JEJ brass gate valve 3 inch for brass gate valve
(1) Sample time:3-5days(without LOGO printing),5-7days(with LOGO printing)
(2) Production time:15-25days(Depends on the Qty) after advanced payment received
(3) Packing:Each into individual polybag,packing into export carton
We export our products to more than 50 countries. We have more than 4 years experience on Alibaba.
1.American: USA, Canada, Ecuador, Peru, Chile, Agentina, Brazil, Mexico, Uruguay, Afgentina, Colombia, Costa Rica ect.
2.Europe: Germany, Holland, France, Spain, Hungary, Russian, Ukraine, Malta, UK, Portugal ect.
3.Asia: Iran, Israel, U.A.E. Saudi Arabia, Thailand, Singapore, Philippine, Vietnam, ect.
4.Africa: Libya, Egpt, Morocco, Algeria. ect.
The new factory of JINERJIAN has fully opening in May.New factory is using 5S management style.
We are connecting huge numbers of customers from all corners of the world,provide more valuable services with clien's satisfaction.
JEJ brass gate valve 3 inch for brass gate valve
1.Nominal Pressure:1.6MPa
2.Suitable Medium :Water,Saturated Steam,Oil, Ga
s 3.Working Temperature:-20~180
4.Thread : ISO 07
5.Solder Socket To ANSI B16/18
6.Size: 1/2" ~ 4"
7.Delivery: In 30 Days
To make a suit solution for the project , we need following information.
JEJ brass gate valve 3 inch for brass gate valve
1.Design standard.
2.Connection standard .
3.Size.
4.Body material .
5.Trim (Material for inside parts).
6.Connection type.
7.Medium.
8.Temperature.
9.Ambient temperature range . Corrosion considerations.
10.Operation type.Application Descripetion.
11.Painting color.
12.Label content.
13.For OEM & ODM , We need your authorization letter.
Payment Terms:T/T L/C
Delivery Time:5-25 days
Price Terms:
FOB Tianjin
CIF specified port
Quality Control:
1.We have more than 150 body moulds of butterfly vavle for you to choose!
2.Each vavle is taken for two times test pressure before leave factory!
3.Every valve has 24 months guarantee period.
4.MOQ:
1 Piece,it is up to which size clients want.
...
