Indoor application LCD 46" splicing video wall
Features:
Ultra-narrow border design of the current width of only 3.5mm double edge
Industrial grade professional DID LCD screens, designed for industrial monitoring and multimedia information display
Various display modes such as Full screen display, Display separately on each screen, Free combining display, Picture roaming, Picture overlying, Picture stretch
Support 7x24 hours, 365 days of continuous power-on, high reliability and stability, product life up to 60,000 hours
All screens can display the same or different signal sources on a single screen
Combinations :2x2, 2x3, 3x3, 3x4, 4x4, 5x4, 5x5 or any combination customized
Performance:
Response time is less than 6ms, which is prompt
Embedded 3D digital signal noise reduction, support 1920*1080 resolution.
Signal interface --- RS232, HDMI, DVI, VGA, YPbPr, AV
RS232 control, easy operation for the system by control software
Specs |
Model No. |
XS-4600HD-SNL3 |
Panel type |
SAMSUNG TFT-LED |
|
Resolution |
1920x1080 |
|
Bezel |
3.5mm (UP:2mm; DOWN:1.5mm; LEFT:2mm; RIGHT:1.5mm) |
|
Display area |
1018.08(W)*572.67(H) |
|
Pixel pitch (HxV) |
0.176(H)*0.530(V) |
|
Brightness |
500cd/m2 |
|
Contrast |
4500:1 |
|
Viewing angle(H/V) |
178/178(H/V) |
|
Response Time |
6ms |
|
Input and output |
VGA input |
1 |
DVI input |
1 |
|
HDMI input |
1 |
|
BNC input |
2 |
|
BNC output |
1 |
|
RS232 output |
1 |
|
Power supply |
AC voltage |
AC100~240V;50/60HZ |
Power consumption |
≤180W |
|
Standby |
<3W |
|
Temperature |
0℃-40℃ |
|
Physical |
Weight |
30KG |
Menu language |
Chinese / English |
|
Body dimension(Wx H x D)mm |
1021.98mm(W)x576.57mm(H)x72.1mm(D) |
|
Installation |
Wall-mounted, floor stand, cabinet installation optional |
Widely used in Military command and control center, Airport, Financial, Metro, shopping mall, supermarket, Public place, assembly room, Studio room, Enterprise, Government ,Movie Theater, Hotel, night club, Public security, Transportation, Electrical Power , Energy sources, coal mine, etc.
The reason why choose us?
1, We are professional manufacturer for digital signage, lcd video wall,cctv lcd monitor, touchscreen all-in-
one, etc.
2, We could provide OEM/ODM service for all kinds of customers. Our proffesional support team will service
online 24 hours for customers.
3, We have a very strong quality control.
4, Samples are always available for checking quality and can be dispatched to you very quickly.
5, Experienced R&D and QC staffs guarantee the product quality and keep updating products and technology.
6, Warranty (1-3 year)
Indoor application LCD 46" splicing video wall
Indoor application LCD 46" splicing video wall
Indoor application LCD 46" splicing video wall
