BNM-40 Mobile Concrete Mixing Plant

Specifications

BNM-40 Mobile Concrete Mixing Plant
1.Capacity: 40m3/h
2.Mixing Time: 60S
3.Discharging Height: 3.8m
4.Total Weight: 17 Ton

BNM-40 Mobile Concrete Mixing Plant



Dongfeng Mid-South Enterprise., Ltd, the subsidiary company of Dongfeng group. As one of the three major automobile manufacturing group in China, the group’s sales volume is USD57 billion in 2011 and ranked No143th among world’s top 500 enterprises. The sale of Dongfeng commercial vehicle ranked globally top by the reports of OICA and VDA and ranked No. 2 all over the world.



1.Truck: Dump truck, Cargo truck, Tractor truck, Military truck with varies specification, can satisfy many kinds of your need.
2.Special commercial vehicles: Concret mixer, Garbage truck, Sweeper truck, Water tanker truck, Sewage suction truck, Ambulance, Refrigerated truck, Fire truck, Crane truck and so on. Say any kind of you request.
3.Passenger vehicle: Bus, Coach, Pickup, SUV, MPV, sedan car and so on
4. Construction machinery: Concret mixer, Concrete delivery equipment, Road roller, Wheel loader, Excavator, Forklift, etc.
5. Auto parts: tyres, engine, lubricant etc.



Specification:



Descriptions of BNM-40 Mobile Concrete Mixing Plant:

The modular design without foundation and commissioning enables the mobile concrete mixing plant convenient movement and quick installation. It only takes three days from installation to use. All necessary facilities such as: control room, laboratory and maintenance room are equipped. Cost effective. It is an ideal choice for engineering.



General Information of BNM-40 Mobile Concrete Mixing Plant:

Capacity: 40 m³/h

Mixing Time: 60 S

Max Aggregate Size: 60/80 mm

Discharging Height: 3800 mm

Total Power: 75 kw

Total Weight: 17 Ton

Total Dimensions: 15000×4150×7800 mm

Transportation: Truck Trailer



Technical Parameters of BNM-40 Mobile Concrete Mixing Plant:

1. MIXING SYSTEM

Twin Shaft Concrete Mixer: JS750

Volume:1250 L

Capacity:750 L

Paddle quantity:16 pieces

Paddle Speed: 30.5 r/min

Mixing Motor: 37 kw



2. AGGREGATE SYSTEM

2.1Aggregate Batcher: PLD1200

Volume: 4×5m³=32

Sort of aggregate: 4

Capacity: 60 m³/h

Power: 7.5 kw

Sand vibrator: 0.37kw×2

2.2. Aggregate Belt Conveyor   1 unit

Width: 800 mm

Length: 18456mm

Speed: 1.6 m/s

Motor: 7.5 kw



3. CEMENT SYSTEM

3.1 Cement Silo  2 units
Capacity:50 Ton×2=100 Ton

Silo Diameter: Φ2800

3.2 Cement Screw Feeder     2 units

Diameter: Φ219 mm

Length: 9 m



4. ADDITIVE SYSTEM

Additive silo capacity: 1 m³

Pneumatic valve: Φ50 mm

Pump: 3kw



5. WATER SYSTEM

Submersible pump: 3kw

Water pump: 0.75kw

Water tank: 3 m³



6. AIR SYSTEM

Air Compressor: 1 unit

Power: 7.5kw

Pressure: 0.7Mpa

Air flew: 0.8 m³/min



7. WEIGHING SYSTEM

7.1 Aggregate weighing    1 unit

Weighing Capacity: 1.6 m³

Precision: ±2%

7.2 Cement weighing   1 unit

Weighing Capacity: 1m³

Precision: ±1%

7.3 Water Weighing   1 unit

Weighing Capacity: 150 kg

Precision: ±1%

7.4 Additive Weighing   1 unit

Weighing Capacity: 40 kg

Precision: ±1%



8. CONTROL SYSTEM:

PLC command and control operation

Main electrical components: Schneider

17’’ colorful computer

Manuel and Auto Control is freely changeable
