Help CenterDongfeng LPG Tank Trailer
US$ 45,000 - 60,000
MOQ: 2 Units
Key Specifications
Get Latest Price
Type:
Semi-Trailer
Material:
Steel
Certification:
CE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dongfeng 3-axle LPG Tank TrailerUS$ 45,000 - 60,000MOQ: 2 Units -
Dongfeng Low Bed Tractor TrailerUS$ 14,590 - 19,560MOQ: 2 Units
-
Dongfeng Tractor TrailerUS$ 14,590 - 19,560MOQ: 2 Units
-
Heavy Duty Dongfeng Crude Oil Tank Trailer/ Fuel Tanker Semi-trailerUS$ 20,000 - 40,000MOQ: 1 Set
-
Strong Loading Capacity Dongfeng Crude Oil Tank Trailer/ Tank Trailer/for Oil TransportUS$ 20,000 - 40,000MOQ: 1 Set
Type
Semi-Trailer
Material
Steel
Certification
CE
Size
6880x1310x1310
Max Payload
17965
Place of Origin
Hubei, China
Brand Name
Dongfeng
Model Number
DFL4251A
Specifications
Dongfeng LPG tank semitrailer:1. High quality.
2. Attractive quotation.
3. Professional after-sale service.
Dongfeng LPG Tank Trailer Specification
| Truck | Drive Mode | 6×4 | |
| Chassis | DFL4251A | ||
| Engine | Model | Cummins 375 30 | |
| Type | 6-cylinder in line, turbocharging, air cooling, inter cooling, electrical control common-rail engine | ||
| Max. power(Kw/rpm) | 275/2200 | ||
| Max. torque(N.m/rpm) | 1400/1300-1500 | ||
| Bore /Stroke(mm) | 114×145 | ||
| Displacement(ml) | 8900 | ||
| Type of fuel | Diesel | ||
| Compression ratio | 16.6:1 | ||
| Gearbox | Model | Fast 12JS180T | |
| Max.torque(N.m/rpm) | 1800 | ||
| Dimensions | Overall dimension (mm) | 11980×2500×3200 | |
| Wheel base (mm) | 3400+1350 | ||
| Front/Rear tread(mm) | 2027/1820 | ||
| App./Dep. Angle(°) | 18/32 | ||
| Mass | Payload (kg) | 17965 | |
| Curb weight(kg) | 12505 | ||
| G.V.W (kg) | 30600 | ||
| Typre | 11.00R20 | ||
| Special functions | Overall dimension of tank (Length*Macro axis*Minor axis) (mm) | 6880+1310+1310 | |
| Effective Volume(m³) | 56.14 | ||
| Tansport Medium | all kinds of oils, chemical liquids | ||
| Material of tank | carbon steel | ||
| Transport medium: liquefied petroleum gas (LPG), unit volume filling quality of 0.42 t/m3, the type of item no. : 2.1, the effective volume of tank: 56.14 cubic meters, the shape of tank size (length x diameter) (mm) : 12796 x 2478. Tanks straight segment length is 10290 mm. With the speed limit device of the tractor. Protective materials: Q235A carbon steel, connection mode: left and right side and bottom protection are connected by welding, the back of the protective section size (mm) : 100 * 50 * 5, the back of the protective ground height (mm) : 460. ABS models: ZQFB - V. | |||
