32 inch LCD CCTV Monitor
Features:
Chinese/English OSD menu, easy to operate |
Ultra thin design, easy to use, fashionable appearance |
High contrast, high brightness, greatly improve the image layering, can perform details better |
Automatic elimination of blur function, protect the LCD screen for long-term use |
Adopt the latest 3D digital decoding and image noise reduction technology |
A variety of digital image correction circuit, minimize image distortion |
16.7M display, the picture is more natural and delicate |
5ms fast response time, screen no tail |
Support two signals input simultaneously, PIP position and size optional, maximize the use of display |
Latest I²C bus control circuit, high reliability, good expansibility |
Multiple input signals(CVBS/YPBPR/VGA/HDMI/RCA) |
Built-in power, low consumption, long life time 60000hrs |
Equipped with a sensitive infrared receiver, can adjust the monitor parameters via remote control |
Ultra quiet cooling fan design |
Full metal casing design, strong anti-electromagnetic shielding, no radiation |
Model No. |
XS-3200HD-P |
|
Panel |
Size |
32”(16:9) |
Type |
LCD |
|
Resolution |
1920x1080 |
|
Display area |
698.4(W)x392.85(H) |
|
Pixel pitch |
0.36375mmx0.36375mm |
|
Brightness |
500cd/m2 |
|
Contrast |
1000:1 |
|
Response time |
5ms |
|
Viewing angle |
178°(H)x178°(V) |
|
Field frequency |
50HZ, 60HZ, 70HZ |
|
Color |
Display color |
16.7M |
Max color |
Full Color |
|
Color system |
PAL/NTSC |
|
Input/Output |
CVBS input |
BNCx5 |
YPBPR input |
1(BNCx3) |
|
DVI input |
DVIx1 |
|
HDMI input |
HDMIx1 |
|
VGA input |
VGAx1 |
|
CVBS output |
BNCx2 |
|
Audio |
Audio input |
RCAx2 |
Power consumption |
Power supply |
AC100~240V,50/60HZ |
Max consumption |
≤120W |
|
Standby |
≤3W |
|
Working environment |
Temperature |
0℃~50℃ |
Relative humidity |
10%~90% |
|
Storage environment |
Temperature |
-25℃~60℃ |
Relative humidity |
5%~95% |
|
Dimension |
Body dimension |
773.6mm(W)x470mm(H)x118mm(D) |
Packing dimension |
856mm(W)x560mm(H)x163mm(D) |
|
Weight |
N.W. |
15kg |
G.W. |
16.5kg |
|
Installation |
Installation method |
Wall mounted, desktop optional |
Others |
Operation method |
Panel buttons, IR remote control |
Cooling system |
Single fan cooling |
|
Casing material |
Full metal casing |
|
Environment standards |
All components and packing materials comply with international environment standards |
|
Accessories |
User manual, warranty card, remote control, AC power cable |
|
The reason why choose us?
1, We are professional manufacturer for digital signage, lcd video wall,cctv lcd monitor, touchscreen all-in-one, etc.
2, We could provide OEM/ODM service for all kinds of customers. Our professional support team will service online 24 hours for customers.
3, We have a very strong quality control.
4, Samples are always available for checking quality and can be dispatched to you very quickly.
5, Experienced R&D and QC staffs guarantee the product quality and keep updating products and technology.
6, Warranty (1-3 year)
