High temperature anti-sticking cloth

Specifications

1.easy to clean the spot
2.anti-corrosion,oxidative resistance
3.high-temp resistance
4.anti-sticking
5.used as oven liner



high temp anti-sticking cloth is made up of high-capability fiberglass which has steeped into PTFE. It is a new product with high capability and multiform function of complex material.

Main capability and characteristics:
1).It can be used under the temperature of -140°C to 360 °C, which has the capability of weather resistant and age resistant. Under practical situation of high temperature of 250 °C for 200 days, not only the intensity will not decrease, the weight will not reduce; if put it under the high temperature of 350 °C for 120 hours, the weight only decreased by about 0.6%; under the situation of -180 °C, it will not chap and keep the original pliability;
2).Hardly to adhere any material; it is easy to wash away the blot or other dust such as resin, coating material, etc.
3).Chemical corrosion resistant, it could resist acid, alkali, aqua fortis and various kinds of organic liquid corrosion;
4).Low ratio of friction (0.05-0.1), it is the best choice of non-oil lubricator;
5).Light piercing ratio is 6-13%;

Main sorts and specifications:
Thickness: 0.06-1.0mm;
Structure of basal fabric: plain, diagonal, satin, etc.
Width: 1000-4200mm;
Color: brown, white, black, black-argent;
Way of coating: double-faced coating, single-faced coating, ventilate coating, static resistant coating.

Applied range:
1. Internal gasket, cushion, covering fabric, conveyer belt which resisting viscidity; base on the different thickness, it could be used as conveyer belt, conglutinating belt, sealing belt of various kinds of drying machine;
2. welding of plastics, welding cloth for solder; plastic patch, membrane, belt of heat enveloping patch;
3. High insulation of electric: insulating belt of electric, septa, cushion, gasket. High frequency plank coated with copper;
4. heat resisting envelope, terrace base-material, enswathing of heat insulation;

Item	color	thickness	width	weight	Tensile strength	Temp-Resistance
H008AJ	brown	0.08mm	1250mm	165g/m²	130/120N/cm	-140 to 360°C
H008BJ	black	0.08mm	1250mm	170 g/m²	130/120N/cm	-140 to 360°C
H008Y	black	0.08mm	1250mm	185 g/m²	130/120N/cm	-140 to 360°C
H013AJ	brown	0.13mm	1250mm	260 g/m²	220/190N/cm	-140 to 360°C
H013BJ	black	0.13mm	1250mm	275 g/m²	220/190N/cm	-140 to 360°C
H013Y	black	0.13mm	1250mm	290 g/m²	220/190N/cm	-140 to 360°C
H018AJ	brown	0.18mm	1250mm	395 g/m²	330/250N/cm	-140 to 360°C
H018BJ	black	0.18mm	1250mm	415 g/m²	330/250N/cm	-140 to 360°C
H025AJ	brown	0.25mm	2800mm	490 g/m²	410/330N/cm	-140 to 360°C
H025BJ	black	0.25mm	2800mm	510 g/m²	410/330N/cm	-140 to 360°C
H035AJ	brown	0.35mm	3200mm	660 g/m²	560/445N/cm	-140 to 360°C
H035BJ	black	0.35mm	3200mm	680 g/m²	560/445N/cm	-140 to 360°C
H040AJ	brown	0.40mm	3500mm	780 g/m²	820/500N/cm	-140 to 360°C
H040BJ	black	0.40mm	3500mm	820 g/m²	820/500N/cm	-140 to 360°C
H065AJ	brown	0.65mm	4000mm	1150 g/m²	1080/750N/cm	-140 to 360°C
H090AJ	brown	0.90mm	4000mm	1550 g/m²	1500/1250N/cm	-140 to 360°C
H090BJ	black	0.90mm	4000mm	1650 g/m²	1500/1250N/cm	-140 to 360°C
