Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > 2MP hd Tvi Camera, HD Dome TVI Camera, 1080P TVI Camera With OSD

2MP hd Tvi Camera, HD Dome TVI Camera, 1080P TVI Camera With OSD

Name: 2MP hd Tvi Camera, HD Dome TVI Camera, 1080P TVI Camera With OSD
Brand: ISEC
SKU: 100470793
Availability: InStock

US$ 20 - 30 MOQ: 1 Unit

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ISEC

Model Number:

IC-LBW20-MV series

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ISEC

Model Number IC-LBW20-MV series

Type Analog Camera

Style Bullet Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Product Description

2MP hd tvi camera, HD dome TVI camera, 1080P TVI camera with OSD

Features:

> 720P/1080P TVI camera

> 3.6mm lens,2.8/6mm lens option

> D-WDR, 3DNR, Digital Zoom, Defog, Motion Detection etc.

> 24pcs Ø5mm IR LED, about 20 meters IR distance

Specifications:

Model NO.	IC-LBW20-MV7	IC-LBW20-MV7 B	IC-LBW20-MV72
VIDEO
Image Device	1/4" 1MP AR0141 CMOS	1/3" 1.3MP AR0130 CMOS	1/3" 2MP IMX222 CMOS
DSP	HD8060	HD8060	NVP2421
TVI Chip	TP2801
TV System	PAL/NTSC
Effective Pixels	1280(H)×720(V) , 1MP	1280(H)×720(V) , 1MP	1984(H)*1225(V) 2MP
Scanning System	Progressive Scan
Synchronization	Internal
Image Resolution	1280*720(720P)	1280*720(720P)	1920*1080(2MP)
Frame rate	PAL: 25fps 720P(1280×720); NTSC: 30fps 720P(1280×720)
Min. Illumination	Color: 1.0lux F1.2; B/W: 0 Lux(IR ON)
S/N Ratio	>50dB
LENS
Focal Length	3.6mm lens,2.8/6mm lens option
IR-CUT	3MP IR filter cut
OPERATIONAL( OSD MENU)
Day & Night	Auto		AUTO /COLOR /B/W /EXT
D-WDR	NA		OFF/ON/AUTO
Noise Reduction	NA		3DNR(Low, Middle, High,OFF)
Back Light	Auto		On/Off
Auto Gain Control	Auto		Low, Middle, High,OFF
Defog	NA		OFF / ON
Motion Dectection	NA		ON/OFF , 4 ZONE
Sense Up	NA
Digital zoom	NA		62x
Pricacy Mask	NA		ON/OFF , 8 ZONE
Electronic Shutter Speed	Auto		1/25(1/30) s to 1/50,000 s
White Balance	Auto		White Balance Auto/ Manual/AWC-SET
Brightness	NA		Adjustable
Mirror	NA		ON/OFF
Sharpness	NA		Adjustable
OSD Language	NA		Simplified Chinese, traditioanl Chinese, English, Russian Turkish,Dutch ,portuguese, spanish.Italian,French, German,Polish
General
Infrared LED	24pcs Ø5mm IR LEDs
IR Distance	about 20 Meters
Infrared Spectrum	850nm
Input Current	400mA
Adapter Requirement	DC 12V, 1A
Water-proof	IP66
MECHANICAL
Color	White case
Bracket	/
Dimensions	Ø119X83(H)mm
Net Weight	0.85kg/pcs
ENVIRONMENTAL
Operation Temperature	-10°C~ +50°C
Storage Temperature	-20°C~ +60°C
