New Products on China Market HD TVI Camera, 2MP Dome TVI Security Camera

Name: New Products on China Market HD TVI Camera, 2MP Dome TVI Security Camera
Brand: ISEC
SKU: 100470911
Availability: InStock

US$ 26.9 - 26.9 MOQ: 1 Unit

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ISEC

Model Number:

IC-LD20-DV2C

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ISEC

Model Number IC-LD20-DV2C

Type Analog Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Product Description

New products on china market HD TVI camera, 2MP dome TVI security camera

Features:

> 720P/1080P TVI camera

> 3.6mm board lens 2.8/6mm lens are optional

> D-WDR, 3DNR, Digital Zoom, Defog, Motion Detection etc.

> 22pcs Ø5mm IR LED, about 20 meters IR distance

Specifications:

Model NO.	IC-LD20-DV2C
VIDEO
Image Device	1/3" 2MP CMOS Sensor
DSP	IMX322+FH8531
TVI Chip	TP2801
TV System	PAL/NTSC
Effective Pixels	1984(H)*1225(V) 2MP
Scanning System	Progressive Scan
Synchronization	Internal
Image Resolution	1920*1080(2MP)
Frame rate	PAL: 25fps 720P(1280×720); NTSC: 30fps 720P(1280×720)
Min. Illumination	Color: 1.0lux F1.2; B/W: 0 Lux(IR ON)
S/N Ratio	>50dB
LENS
Focal Length	3.6mm board lens 2.8/6mm lens are optional
IR-CUT	3MP IR filter cut
OPERATIONAL( OSD MENU)
Day & Night		AUTO /COLOR /B/W /EXT
D-WDR		OFF/ON/AUTO
Noise Reduction		3DNR(Low, Middle, High,OFF)
Back Light		On/Off
Auto Gain Control		Low, Middle, High,OFF
Defog		OFF / ON
Motion Dectection		ON/OFF , 4 ZONE
Sense Up	NA
Digital zoom		62x
Pricacy Mask		ON/OFF , 8 ZONE
Electronic Shutter Speed		1/25(1/30) s to 1/50,000 s
White Balance		White Balance Auto/ Manual/AWC-SET
Brightness		Adjustable
Mirror		ON/OFF
Sharpness		Adjustable
OSD Language		Simplified Chinese, traditioanl Chinese, English, Russian Turkish,Dutch ,portuguese, spanish.Italian,French, German,Polish
General
Infrared LED	22pcs Ø5mm IR LEDs
IR Distance	about 20 Meters
Infrared Spectrum	850nm
Input Current	400mA
Adapter Requirement	DC 12V, 1A
MECHANICAL
Color	White case
Bracket	/
Dimensions	Ø127X97(H)mm
Net Weight	0.45kg (Volume: 0.55kg)
ENVIRONMENTAL
Operation Temperature	-10°C~ +50°C
Storage Temperature	-20°C~ +60°C
