Button Mini Motion Sensor Security Camera

Specifications

Mini Square Motion Sensor Security Camera
-3.7mm Botton Appearance Lens
-CE FCC ROHS
-2 year warranty
-Paypal Accept



Button Mini Motion Sensor Security Camera



Features:



♦ Latest Security Systems Design.



♦ Easy installation Mini Bullet Camera.



♦ 420/550/650TV Lines optional, 650TV Lines built OSD menu.



♦ 1/3 Sony  Low Illumination Ccd , 1/4 Sharp Ccd, all original.



♦  3.7mm button appearance lens .



♦ 2 years warranty, CE/FCC/RoHS certificate approved.



♦ High Quality Cctv Cameras' manufacturer and supplier.



♦ Size Optional: 26x26   30x30   34x34 (mm)



♦ DC12V Power supply .







Square Minature Camera
Model No	Specification	Size(mm)
IC-2250CP2	1/3" SONY Low Illumination CCD, 420TVL, 0.1Lux, 3.7mm button appearance lens	26x26
IC-2250CDNP2	1/3" SONY Low Illumination CCD, 420TVL,0.1(color)/0.05(B/W), 3.7mm button appearance lens	26x26
IC-2303CP2	1/4" Sharp CCD, 420TVL, 1.0Lux, 3.7mm button appearance lens , audio is optional	30x30
IC-2301CP2	1/4" Sony CCD, 420TVL, 0.5Lux, 3.7mm button appearance lens , audio is optinal	30x30
IC-2300CP2	1/3" SONY Low Illumination CCD, 420TVL, 0.1Lux, 3.7mm button appearance lens , audio is optinal	30x30
IC-2300CDNP2	1/3" SONY Low Illumination CCD, 420TVL, 0.1(color)/0.05(B/W), 3.7mm button appearance lens , audio is optinal	30x30
IC-2343CP2	1/4" SHARP Low Illumination CCD, 420TVL, 0.5Lux, 3.7mm button appearance lens , audio is optional	34x34
IC-2340CP2	1/3" SONY Low Illumination CCD, 420TVL, 0.1Lux, 3.7mm button appearance lens , audio is optinal	34x34
IC-2340CDNP2	1/3" SONY Low Illumination CCD, 420TVL, 0.1(color)/0.05(B/W), 3.7mm button appearance lens , audio is optinal	34x34
IC-2345CP2	1/3" SONY Low Illumination CCD, 550TVL, 0.1Lux, 3.7mm button appearance lens , audio is optinal	34x34
IC-2345CDNP2	1/3" SONY Low Illumination CCD, 550TVL, 0.1Lux, 3.7mm button appearance lens , audio is optinal	34x34
IC-2346CP2	1/3" Sony Low Illumination CCD, 650TV Lines, 3.7mm button appearance lens , B/W and COLOR mode can be adusted, DWDR, built-OSD, OSD cable	34x34
Image Pick-up Device	1/3" SONY COLOR CCD, 1/4" SHARP Low Illumination CCD
Horizontal Resolution	420TV Lines,     550TV Lines,     650TV Lines,
Camera Lens	3.7mm button appearance lens
Number of Pixels	NTSC:510(H)x492(V); PAL:500(H)x582(V)
Scanning System	NTSC:525 Lines,60 Field/sec,
	PAL:625 Lines 50 Field/sec
Sync System	Internal Synchronization
Gamma Characterlstic	'0.45
S/N Ratio	more than 48dB(AGC Off)
Electronic Shutter Time	NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Minimum Illumination	0.05Lux
Video Output	1.0Vp-p 75 ohm
Gain Control(AGC)	Auto
Operation Temperature	-10C~ +50C RH95% MAX
Storage Temperature	-20C~ +60C RH95% MAX
Power Supply	DC12V+_10%,120mA
Case	Black







Camera Package:

















Camera Application:





Welcome to Isec Factory !











Camera Certificates:







♦  Logo Printing, OEM order welcome



Contact us now ! We are quiet ready for you !
