Waterproof Outdoor High Definition Sercurity SDI Camera

Name: Waterproof Outdoor High Definition Sercurity SDI Camera
Brand: ISEC / OEM / Neutral
SKU: 100467479
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ISEC / OEM / Neutral

Model Number:

IC-LBMW40-FSD

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ISEC / OEM / Neutral

Model Number IC-LBMW40-FSD

Type Analog Camera

Style Bullet Camera

Sensor CMOS

Technology Other, HD-SDI 1080P

Special Features Waterproof / Weatherproof

Waterproof Outdoor High Definition Sercurity Camera

Main Features

♦ HD Camera

♦ Built in OSD, controlled by cable.

♦ High Definition Mega Pixels HD-SDI Camera
♦ 1/3''Progressive scan CMOS Sensor.

♦ HD-SDI / Analog Output, real time transmission, work simultanous.

♦ WDR, AGC, DSS, BLC, ACE
♦ 3DNR, Demist, Digital Zoom

♦ IP66, Fully weatherproof and dustproof, perfect choose of hd sdi camera.

♦ Built-in 42pcs infrared LEDs, 40m IR distance night vision.

♦ 2.8-12mm 2MP Lens (6-15/9-22mm lens optional).

♦ CE/FCC/RoHS certificates.

♦ 2 years warranty.

♦ Gray case.

♦ Easy installation, Aluminum Alloy Housing.

♦ High Quality Cctv Cameras' manufacturer and supplier

Detail Pictures

Specification :

Model No		IC-LBMW40-ASD
Imaging Sensor		1/3'' Panasonic CMOS(MN34041PL)
Total Pixels		2010(H) x 1108(V) = 2,227,080 (pixel)
Scanning system		Progressive Scan
Resolution		1920x1080p
Min. illumination		Color : 1.0 lux , BW : 0.5lux
S/N Ratio		More than 50dB (AGC off)
Video Output		HD-SDI / Analog
Lens		2.8-12mm 2MP lens, 6-15/9-22mm 2MP lens optional
Brightness		0 ~ 20
Shutter		AUTO / MANUAL
AGC		0 ~ 20
Backlight		OFF / HLC / BLC / WDR
Day & Night		AUTO / COLOR / B&W / EXT
White BAL		AUTO / AUTOext / PRESET / MANUAL
DNR		OFF / LOW / MIDDLE / HIGH
Sharpness		0 ~ 10
Mirror		ON / OFF
FLIP		ON / OFF
D-WDR		OFF / LOW / MIDDLE / HIGH
Frame Rate		25 FPS / 30 FPS
IR LED		42pcs Ø5mm IR LEDs
IR distance		40 meters
Power		DC12V, 500mA
Storage Temperature		-20°C ~ +60°C (Humidity : 0%RH ~ 90%RH)
Waterproof		IP66
Braket		bottom screws for zoom/focus adjustment, cable is built in bracket
Dimension		147(W) x80(H) x84(D)mm
Case Color		gray case
weigt		1.35kg
