150W Universal Laptop Ac/dc Adaptor

Name: 150W Universal Laptop Ac/dc Adaptor
Brand: Hylook
SKU: 100465025
Availability: InStock

US$ 1 - 10 MOQ: 100 Units

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Hylook

Model Number:

HL-P12-050

Shenzhen Hylook Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Hylook

Model Number HL-P12-050

Output Type DC

Connection Desktop

Specifications

150W Universal laptop ac/dc adaptor
1.Input:110V-240V
2.Output:12-24V
3.Use for:Laptop,LCD monitor,Printers
4.MOQ:100Pcs

150W Universal laptop ac/dc adaptor

Features

100% Brand New
This model is an universal switching - mode power supply for laptop and LCD Monitor
Output power 150 Watt max, with protection functions : overload protection , Short Circuit Protection, power supply by mains supply.
With 8PCS tip connection suit to almost Laptops
For Sharp, HP, Samsung, IBM, Toshiba, Sony, Compaq and Panasonic Laptops
Select output voltage suit to laptop and LCD monitor
Make sure that polarity of tips connect correct before use.
Normal Operating Temperature and Humidity:
Operating Temperature : 0°C to 40°C Humidity : 20% to 80%
Storage Temperature and Humidity:
Storage Temperation : -10°C to 70°C Humidity 10% to 90%
USB port voltage:
-USB limited current: 1.0A max

Electric Characteristics:

NO	Item	Specification
1	Rated Input Voltage (50 - 60Hz)	AC 120V OR AC230V
1	Vibration Input Voltage Range (47 - 63 Hz)	AC 100V - 240 V
2	Input Rated Current	1.5 AMP
2	Input Power	100VA
3	Output power (max)	150W
3	Efficiency	>88% (TYP)
4	Output voltage : DC 12V/15V/16V/18V/19V/20V/24V(0.2/+0.8V NO LOAD)	DC15V - 24V
5	150W Output current : 12V/15V 4A MAX. 16V/18V/19V/20V 3.5A MAX. 24V at 2.9A MAX	Output voltage: DC15V/15V/16V/18V/19V/20V/22V /24V ( -0.9/+0.8V at rating load)
6	Overload protection	YES
7	Short Circuit protection	YES
8	Line Regulation	+/-5%
9	Load Regulation	+/-5%
