800tvl Indoor lastest cheap hidden camera(IC-H-C SERIES)

Specifications

Indoor Smoke And Fire Detector (IC-H-C SERIES)
-2 Years Warranty (fcc/ce/rohs)
-100% cctv manufacturer
-Cctv
-Smoke Sensor

Indoor Smoke And Fire Detector (IC-H-C SERIES)







Features





1. Smoke Detector Hidden Camera
2. Sony Color CCD or Sharp Color CCD option

3. Sony Low Illumination CCD 0.1lux

4. Sharp ccd 0.5lux

5. High definition up to 800TVL(700/650/540/480/ 420TVL option)

6. 800TVL to 650TVL camera with built-in OSD, controlled by OSD cable

7. Standard lens:  3.6mm board lens     2.1/2.8/6 mm pinhole lens are optional
8. Without IR LED

9. Ø120x56mm
10. 0.25kg



Deatails

Name of products

Indoor Smoke And Fire Detector (IC-H-C SERIES)



Model number

IC-H-C series



Model NO.	IC-H-CSR	IC-H-CHO	IC-H-CSO	IC-H-CSS	IC-H-CSF
VIDEO
Image Device	1/3" SONY 960H CCD	1/3" SHARP 960H CCD	1/3" SONY 960H CCD	1/3" SONY 960H CCD	1/3" SONY Super HAD II CCD
CCD model no.	ICX811AK(PAL) ICX810AK(NTSC)	RJ2341(PAL) RJ2331(NTSC)	ICX811AK(PAL) ICX810AK(NTSC)	ICX811AK(PAL) ICX810AK(NTSC)	ICX633BK(PAL) ICX632BK(NTSC)
DSP model no.	AVS03P	Nextchip 2090E	Nextchip 2090E	Effio-E CSD4140GG	SONY CXD3142R
Horizontal Resolution	800TVL			700TVL	420TVL
TV System	PAL/NTSC
Total Pixels	PAL:1020(H)*596(V) , NTSC:1020H*508(V)				PAL:537(H)*597(V) NTSC:537(H)*505(V)
Effective Pixels	PAL:960(H)*582(V) , NTSC:976H*494(V)				PAL:500(H)*582(V) NTSC:510(H)*492(V)
Scanning System	2:1 Interlace
Synchronization	Internal
Min. Illumination	0.01Lux	0.1Lux		0.01Lux
S/N Ratio	More than 48dB(AGC OFF)
Video Output	1Vp-p,75ohm, BNC
LENS
Standard Lens	built-in 3.6mm board lens
Option	2.1/2.8/6 mm pinhole lens are optional
Audio	optional
OPERATIONAL
Day & Night	Color / BW / EXT Auto-progressive Auto-general	Auto / Color/ B/W / EXT		Auto / Color/ B/W / EXT1 / EXT2	Auto
Day to Night Delay	0-255	1s-30s option		0-255	N/A
White Balance	ATW, D75, D65, D50, CWF, U30, F/A	ATW / AWB / MANUAL / AWC-SET / ANTI.CRL		ATW / PUSH / USER1 / USER2:ANTI CR,MANUAL,PUSH LOCK	Auto
Electronic Shutter Speed	PAL:1/50 ~ 1/100,000sec, NTSC:1/60 ~ 1/100,000sec				Auto
Mirror	ON/OFF	ON/OFF		ON/OFF	N/A
AGC	0-127 option	Low/Mid/High/OFF		0-127 option	Auto
Sharpness	0-7 option	0-31 option		0-7 option	N/A
Contrast	0-99 option	0-255 option		0-255 option	N/A
Backlight	Auto/Low/Mid/High	0-10 option		OFF /BLC /HLC	N/A
Neg.Image	N/A	ON/OFF		N/A	N/A
Menu Language	English, Japanese, German, French, Russian, Portuguese, Spaish	English, Japanese, German, French, Russian, Portuguese, Spaish		English, Japanese, German, French, Russian, Portuguese, Spaish	N/A
HLC	Low/Mid/High	0-255 option		On/Off, 0-255 option	N/A
Privacy Masking	ON/OFF (8 areas)	ON/OFF (8 areas)		ON/OFF (8 areas)	N/A
Privacy Masking Color	OFF/ON(1-8 option)	OFF/ON(0-15 option)		OFF/ON(1-8 option)	N/A
Sense-up
D-WDR	N/A	OFF/ON(0-63 level adjustable)		OFF/ON(LOW, MID, HIGH adjustable)	N/A
Super WDR	0-10 level adjustable	N/A		N/A	N/A
Demist	Auto/Low/Mid/High	N/A		N/A	N/A
Motion Detection	ON/OFF (4 areas)	ON/OFF (4 areas)		ON/OFF (4 areas)	N/A
DNR	3DNR:ON/OFF(0-3 option)	2DNR:ON/OFF (0-15 option)		2DNR:ON/OFF	N/A
D-ZOOM	1-4 level option	N/A		N/A	N/A
ENVIRONMENTAL
Operation Temperature	-10C ~ +50C RH95% MAX
Storage Temperature	-20C ~ +60C RH95% MAX
ELECTRICAL
Input Voltage/Current	DC12V, 380mA
Adapter Requirement	DC12V 1A
MECHANICAL
Case Color	Standard color: White
Bracket	N/A
Dimensions	Ø120x56mm
Gross Weight	0.25kg
