2015 Hot 4ch/8ch/16ch 720p/1080p AHD DVR for AHD CCTV Camera
4ch/8ch/16ch 720p/1080p AHD dvr for AHD security system
Details:
| Model | IC-AVR1104 | IC-AVR1204 | IC-AVR1208 |
| Main Processor | Hi3520D | Hi3521 | Hi3521 |
| Video & audio input | |||
| Analog video input | 4CH BNC Port | 8CH BNC Port | |
| Audio input | 4CH RCA Port | ||
| Video & audio output | |||
| HDMI output | 800x600,1024x768,1280x1024,1440x900,720P,1080P | ||
| CVBS output | NO | ||
| VGA output | 800x600,1024x768,1280x1024,1440x900,720P,1080P | ||
| Audio output | 1CH RCA Port | ||
| Video & audio code and decode parameters | |||
| Multi-mode switch | AHD: 4CH*720P(compatible with 960H analog) AHD+IP: 2CH*720P+2CH*IPC1080P; IP: 4CH*1080P; 9CH*1080P |
AHD: 4CH*720P(compatible with 960H analog) AHD+IP: 4CH*720P+4CH*IPC1080P; IP: 9CH*1080P; 9CH*3MP; 4CH*5MP |
AHD: 8CH*720P(compatible with 960H analog) AHD+IP: 4CH*720P+4CH*IPC1080P; IP: 9CH*1080P; 9CH*3MP; 4CH*5MP |
| Video compress standard | H.264 | ||
| Vdieo code resolution | CIF/D1/960H/720P/960P/1080P/3M/5M | ||
| Playback resolution | 720P 4CH 100/120 FPS+1080P 4CH 100FPS ; 720P 4CH 100/120FPS;(It is defined with the mode switch) | 720P 4CH 100/120 FPS+1080P 4CH 100/120FPS ; 720P 8CH 160/192FPS;(It is defined with the mode switch) | |
| Video frame rate | NTSC:1~30FPS/S;PAL:1~25FPS/S | ||
| Video code rate | 256kps/384Kbps/512Kbps/640kbps/768Kbps/1M/1.5M/2M/2.5M/3M/4M/5M/6M/8M | ||
| Code stream mode | combine streams/ video stream | ||
| Audio compress standard | ADPCM | ||
| Audio code rate | 16kpbs | ||
| Dual-stream | YES | ||
| Synchronously playback channels | 1/4CH | 1/4/8CH | |
| Hard driver | |||
| Mode | 1*SATA | ||
| HDD capacity | each port support max 4TB HDD | ||
| External port | |||
| Voice intercom | 1CH RCA Port(Level:2.0Vp-p, impedance:1kΩ) | ||
| Internet port | 1CH RJ45 10M / 100M adaptive Ethernet port | ||
| Serial port | 1PC RS485 | ||
| USB port | 2*USB2.0 | ||
| Alarm input | NO | ||
| Alarm output | NO | ||
| Other | |||
| Power supply | DC12V | ||
| Power consumtion (without HDD) | ≤20W | ||
| Work temperature | -10℃--+55℃ | ||
| Work humidity | 10%--90% | ||
| Case | 0.8U | ||
| Size(W*L*H(cm)) | 255*215*45mm | ||
| Net weight / Gross weight (without HDD) | 0.86 / 1.53 kg | ||
| Color box size | 36*27*8.5cm | ||
| Packing (pcs/carton) | 5 | ||
| Carton size (L*W*H(cm)) | 46*37.5*28.5cm | ||
| Gross weight(kg) | 8.33kg | ||
Application:
Why choose us?
u Provide one-stop-products: from CCTV camera, IP camera, DVR to NVR, video balun, etc to meet your whole project needs.
u 9 years R&D and export experience and leading and professional manufacturer in CCTV industry.
u High quality (material) with competitive and reasonable price.
u 2 year warranty and lifetime maintenance.
u Fast delivery: usually within 3-10 work days since payment arrived.
u Professional technical support; Best pre-sale, sale and after-sale service.
u Welcome OEM & ODM, mixed order.
u CE, FCC, RoHS passed.
Quality Control:
u All raw materials are carefully selected and inspected.
u Advanced production equipment is used and routinely inspected and serviced.
u All operators and employees are thoroughly trained.
u All products have passed the European Union RoHS standard and are CE, FCC certified.
u Professional logistics personnel are employed to control the damage during the physical distribution of products.
Shenzhen Isec Tchnologies Co., Ltd is a leading manufacturer of security dome cameras, cctv camera, analog cameras, IP cameras, HD-SDI cameras, DVR, NVR, and accessories in Shenzhen, China.
