Home > Products > AHD DVR & Kit > AHD 4ch Complete AHD security system 8ch AHD camera kits
AHD 4ch Complete AHD security system 8ch AHD camera kits
- 50000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card PayPal
- 7 inch TFT Monitor DIGITAL Wireless Farm Cctv Systems
- 7 inch TFT Monitor DIGITAL Wireless New Backup Camera Kit with 2.4GHz digital signal
- 7 inch TFT Monitor Digital Reversing Camera System with 2.4GHz digital signal
- 7 inch TFT Monitor Wireless Back Up Systems with 2.4GHz digital signal
- Car Camera Wireless Transmitter System For Bus
- 7inch digital 2.4g wireless surveillance camera system For Bus
Product Details
Place of Origin: | Guangdong, China | Brand Name: | ISEC | Model Number: | IC-LDMW30-FA7 + IC-AVR0401 |
Type: | Analog Camera | Style: | Dome Camera | Sensor: | Other, CMOS, OV9712 |
Technology: | Infrared | Special Features: | Waterproof / Weatherproof |
Product Description
AHD 4ch Complete AHD security system 8ch AHD camera kits
Include:
1Pcs AHD DVR:
1pc*A7104E
4ch AHD DVR, 1ch Audio1080P HDMI, no 3G wifi
support 1*4TB HDD
4Pcs AHD Camera:
4pcs*AHD-5621-A
1mp AHD camera ir cut filter, 30ir, 2.8-12mm manual zoom lens
camera color: black/white
1pc*12V 5A with 1 to 4 splitter
4pcs*15 meters power+video cable
AHD DVR Feature:
System | Model | HS-7104 | ||||||
Main Processor | HI3515 | |||||||
Operating System | Embedded LINUX | |||||||
User Interface | GUI, | |||||||
Display | 1/4 | |||||||
Video | Video Standards | PAL 625 line,50 f/s;NTSC 525 line 60 f/s | ||||||
Video Compression | H.264 | |||||||
Video Recording | D1:PAL 1f/s-25f/s NTSC 1f/s-30f/s | |||||||
Encode Capacity | 100/120fps(D1) | |||||||
Motion Detection | Zones:64(8*8)detection zones | |||||||
Record & Playback | Recording Mode | Manual>Alarm>Video Detection>Continuous | ||||||
Playback | Multi CHs playback simultaneously | |||||||
Search Mode | Time/Date,Alarm,Motion Detection & exact search | |||||||
Storage & Backup | Space Occupation | Audio 28.8MB/H ;Video 25~450 MB/H | ||||||
Record Storage | Local Hard disk and Network | |||||||
Interface | Video Input | 4CH | ||||||
Video Output | 1CH TV output BNC,1.0Vp-p,75Ω,1 VGA output | |||||||
Audio Input | 1CH/4CH | |||||||
Audio Output | 1CH | |||||||
Net Interface | RJ-45 | |||||||
PTZ Control | Support | |||||||
USB Interface | 2 x USB2.0 | |||||||
Hard Disk | 1 SATA ports | |||||||
Dimension | L233*W300*H45 |
AHD camera Feature:
Model | IC-LDW20-FA7 |
Image Sensor | 1/4" 1MP CMOS Sensor |
Horizontal Resolution | 1MP 720P OSD, D-WDR, Sense-up, 3DNR, Defog, HLC/BLC, Privacy Zone Masking, Dynamic Motion Detection |
TV System | PAL/NTSC |
Effective Pixels | PAL:976 (H)× 494(V) NTSC:976 (H) ×582 (V) |
IR LED | 36pcs Ø5mm IR LEDs |
IR project distance | 30 meters |
Lens | standard: 2.8-12mm manual zoom lens |
6-15, 9-22mm lens optional | |
Minimum Illumination | 0 Lux/F2.0 (LED ON) |
IR Status | Under 10 Lux by CDS |
IR Power On | CDS Auto Control |
Scanning System | NTSC:525 Lines,60 Field/sec, |
PAL:625 Lines 50 Field/sec | |
Sync System | Internal Synchronization |
Gamma Characteristic | 0.45 |
S/N Ratio | ≥65dB (AGC OFF) |
Electronic Shutter Time | NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec; |
Video Output | Composite Signal (1.0Vp-p, 75Ω), BNC |
Gain Control(AGC) | Auto |
White Balance | Auto |
Backlight Compensation | Auto |
Operation Temperature | -10C~ +50C RH95% MAX |
Storage Temperature | -20C~ +60C RH95% MAX |
Waterproof | IP66 |
Power Supply | DC12V,400mA |
Dimension | Ø119X83(H)mm |
Camera Case Color | default: white |
weight | 1kg |
AHD cameras effect:
AHD camera kits packaging:
AHD camera kits Shipping:
1. 2 years warranty
2. CE/FCC/RoHS certification
3. DHL, FedEX, UPS, Express, TNT for your optional, door to door.
4. 3~5 work days delivery time.
5. Professional technology team.
6. Friendship based on the businessship.
Company proview:
Contact me:
