Plastic buckets for bucket elevators made in China
FOCUS FM 3G3 Screw Conveyor Features:
-
Specification:
FM-3B3 Z type Conveyor Application:grain bucket elevator conveyors are very well suited for a broad range of free flowing products in the food, agriculture, pharmaceutical, cosmetic, chemical industry, .such as snack foods, frozen foods, vegetales, fruits, confectionary. Chemicals and other granules.
1. The buckets are made of a food grade reinforced polypropylene, molded in one piece and can handle temperatures from -10 to 120 degrees Fahrenheit.
2. The bucket elevators allow for controlled feeds at one or more locations and can easily interface with various types of feeding devices3. All parts have easy to remove inspection covers and a conveniently located inspection window. The buckets have a quick release mechanism to facilitate fast installation or removal of buckets. All elevators are equipped with an automatic chain tensioning device and built-in overload protection.
4. The geared reducer motor drived the machine have a stable performance prolong the machine life and easy to maintenance.
5. Optional parts:
Stainless steel and carbon steel.
Discharge options:
1. Over the end discharge
2. Single or multiple discharges
3. anywhere in circuit available
Technical parameters:
Model |
FM-3B3 Chain Type Bucket Conveyor |
||
Bucket Volume |
1.8L |
3.8L |
6.5L |
Numbers of discharge |
Single |
One or Multi-discharge |
One or Multi-discharge |
Machine structure |
Stainless steel or Painted steel |
||
Production Capacity |
4-6 M3/H |
6.5-8M3/H |
8.5-12M3/H |
Machine packed dimension(mm) |
2080x1430x1160mm |
2600x1350x1000mm |
3000x1550x1200 |
Voltage |
Three phase 380V or single phase 220V, 50HZ/60HZ |
||
Power Supply |
0.75KW |
1.5KW |
2KW |
Packaging Details: 1. Outside Package: standard export poly wood cases, 2, Inner Package: air bubble film.
Shipping: by sea, by train or by air.
1, Customized Machines are Available.
2, Provide Installation instruction and after-service tracing, resolving the clients' concerns.
3, One year guarantee, except for some spare parts.
4, Flexible payment terms and trade terms.
5, Available factory visiting.
6,Other related machines are provided too, such as screw weigher, packaging machine and belt conveyor.
ABOUT US |
MOQ?
1set/sets
Payment?
Alibaba trade assurance(recommended) or TT or L/C or Western Union.
Delivery Time?
Within 20 days after received the payments.
Package way?
Export standard wooden case.
You have any question?
Ask the trademanager contactor directly:):)
We sincerely ask you for a inquiry, welcome to visit our factory!!:):)
