Netis 300Mbps Wireless N VDSL2 Modem Router

Shenzhen Netcore Industrial Ltd.
Netis 300Mbps Wireless N VDSL2 Modem Router thumbnail-1
Netis 300Mbps Wireless N VDSL2 Modem Router photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Wireless
Application:
Enterprise
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Wireless
Application Enterprise
Function QoS, Other
LAN Ports 4
WAN Ports 1
Certification CE, FCC
Brand Name netis
Model Number DL4422
Place of Origin Guangdong, China

netis 300Mbps Wireless N VDSL2 Modem Router

Product Description

DL4422 is a VDSL wireless router. It supports VDSL2 standard, and is compatible with ADSL2+/ADSL2/ and ADSL Standard. VDSL2 supports upload and download speed up to 100 Mbps (whereas ADSL maximum standard is only 24Mbps download speed).  DL4422 is also a 300Mbps Wireless router, which provides 4*100Mbps RJ45 ports. This combination of wired and wireless technology on a shared network will satisfy Users' needs, ensuring a reliable connection while web streaming, online gaming, internet calling, and HD video streaming.



Features

  • 3-in-1 device: VDSL2 modem, 4-port NAT router, and Wireless N access point
  • VDSL2 standards ensuring high-speed Internet access up to 100Mbps downstream and upstream
  • VDSL2/ADSL2+/ADSL2/ADSL multimode
  • VDSL/VDSL2 profiles 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
  • ATM and PTM supported, dual latency
  • Excellent wireless N speed up to 300Mbps
  • Up to 4 additional wireless networks for visitors
  • Built-in firewall to protect against potential Internet attacks
  • QoS technology prioritizing Internet traffic for smooth network experience
  • Port mapping binds specific LAN ports and PVCs for IPTV application
  • Ethernet WAN offers additional connectivity option for cable or fiber modem
  • IPv6 supported for improved network usability and experience
  • Easy wireless security setup at a push of the WPS button
  • Super lightning protection to avoid device damage caused by tough thunderstorms
  • Easy setup wizard providing quick and hassle free installation
Specification
netis 300Mbps Wireless N VDSL2 Modem Router
Hardware
StandardsVDSL2/ADSL2+/ADSL2/ADSL multimode
VDSL/VDSL2 profiles 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a
ATM and PTM supported
Dual Latency
IEEE 802.3/802.3u
IEEE 802.11b/g/n
Interface1* RJ11 DSL Port,
4* 10/100Mbps Auto MDI/MDIX RJ45 LAN Port
(Optional Ethernet WAN for LAN4)
LEDPOWER, LAN4, LAN3, LAN2, LAN1, WLAN, WPS, DSL, Internet
ButtonWPS, RESET, Power ON/OFF
Power Supply      DC 12V/1A (Output)
Software
Data RateDownstream: Up to 100Mbps
Upstream: Up to 100Mbps
ATM / PPP ProtocolATM Forum UNI3.1/4.0 PVC (up to 8PVCs)
ATM Adaptation Layer Type 5 (AAL5)
ATM QoS
Bridged and Routed Ethernet Encapsulation
VC and LLC Based Multiplexing
PPP over Ethernet (RFC2516)
PPP over ATM (RFC 2364)
IPoA (RFC1577/2225)
IPoE (RFC1483 Bridged)
Main FeatureDHCP, DHCP Relay
NAT, Static Routing
VPN (PPTP, L2TP, IPsec) Pass-through
PVC/Ethernet Port Mapping
DNS Relay, DDNS
IGMP Multicast, IGMP Snooping V1/V2
Virtual Server, DMZ, ACL (Access Control List)
UPnP
IPv6
ManagementWeb Based Configuration (HTTP), Remote Management, Telnet Management, Command Line Interface,
TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools
Wireless
Signal Rate                          Up to 300Mbps
Frequency Range2.4-2.4835GHz
Data Transfer Rate802.11n:
40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:
(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:
(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Wireless SecurityWEP 64/128bits,
WPA(TKIP/AES)/WPA2(TKIP/AES)/WPA2 Mixed,
802.1x Authentication
Wireless MAC Filtering
Wireless Security Power20dBm (MAX)
Antenna Type2* 5dBi Fixed Antenna
Others
Certification               CE, FCC
EnvironmentOperating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~90%RH non-condensing
Package1* DL4422
1* 12V/1A Power Adapter
2* RJ11 Telephone Cable
1* RJ45 Ethernet Cable
1* DSL Splitter
1* Quick Installation Guide
 (Multilingual)

Application
