300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE)

300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) thumbnail-1
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) thumbnail-2
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) thumbnail-3
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) thumbnail-4
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) thumbnail-5
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) photo-1
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) photo-2
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) photo-3
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) photo-4
300Mbps Wireless N High Power Ceiling-Mounted Access Point (IEEE 802.3af&at PoE) photo-5
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Used
Brand Name:
netis
Model Number:
WF2520
Contact Supplier Request Quote Chat Now
Shenzhen Netcore Industrial Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Used
Brand Name netis
Model Number WF2520
Place of Origin Guangdong, China

Specifications

speed up to 300Mbps,802.3af&at standard PoE design for flexible deployment,High transmission power to boost wireless signal



Product Description

  The netis 300Mbps Wireless N High Power Ceiling-Mounted Access Point WF2520 provides long range, high performance wireless Internet access over large areas.It provides you multiple wireless modes including Access Point, AP Router, Client, WDS, Repeater, and WISP, for flexible wireless network setup and deployment. Also, with the 802.3af&at PoE design, you may easily establish a solution where electrical socket is unavailable or hard to reach. Under the high power mode, you will enjoy much better network experience in large homes, multi-floor offices or warehouses.





Features
  • Wireless N transfer speed up to 300Mbps



  • High transmission power to boost wireless signal for further distance



  • Provides powerful Wi-Fi coverage that easily penetrates walls obstructions and eliminatesdead zones



  • 802.3af&at standard PoE design for flexible deployment



  • Stylish ceiling-mounted appearance for easy Installation to wall or ceiling surface



  • Supports Access Point, AP Router, Client, WDS, Repeater, and WISP modes



  • Zero configuration under default Access Point mode



  • Quick setup, with built-in multilingual management page



Specification
Wireless
Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Signal Rate Up to 300Mbps
Frequency Range 2.4-2.4835GHz
Transmit Power 30dBm(MAX)
Data Transfer Rates 802.11n:
40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:
(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:
(11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Wireless Modes Access Point, Client, WDS, AP+WDS, Client+Repeater
Wireless Security WEP (64/128-bit), WPA-PSK, WPA2-PSK,
WPA-PSK/WPA2-PSK Mixed Mode
SSID Broadcast Enable/Disable
MAC Address Filtering
Hardware
Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX,
IEEE 802.3af, IEEE802.3at
Interface WAN/PoE: 10/100Mbps Auto MDI/MDIX RJ45 LAN port,
802.3af&at PoE Supported
LAN: 10/100Mbps Auto MDI/MDIX RJ45 LAN port,
LED Indicators System, Wi-Fi
Buttons RESET
Antenna 2* Internal Antenna
Power Supply 802.3af&at PoE
Software
Operation Modes AP, AP Router, WISP
WAN Connection
Types		 DHCP, Static IP,PPPoE, Russia PPPoE,
L2TP/Russia L2TP, PPTP/Russia PPTP
Port Forwarding Virtual Servers, UPnP, DMZ
QoS Bandwidth Control
Access Control MAC Filtering
Others Dynamic DNS, Firmware Upgrade, Backup & Restore
Others
Certification FCC, CE
Environment Operating Temperature: 0℃~40℃
Storage Temperature: -40℃~70℃
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package 1* WF2520
1* Mounting Kit
1* Ethernet Cable
1* Quick Installation Guide
