TOM-L650 Two Axis Rail Series Vertical CNC Milling Machine Frame

US$ 14,168 - 15,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

TOM

Model Number:

TOM-L650

Taian Haina Spindle Science & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name TOM

Model Number TOM-L650

Specifications

height of Lathe bed pad:30
machine net weight:4t
Right and left stroke (X) :600
Front and Rear stroke (Y) 500

Product Description

mm model	TOM-L650
Dimension of worktable surface	500×800
Right and left stroke (X)	600
Front and Rear stroke (Y)	500
Up and down stroke (Z)	500
distance between Spindle center to column guide rail	560
distance between the spindle to the work surface	110-610
The workbench T slot (number - size x spacing)	3-18×144
The spindle taper hole (model/install size)	BT40/ Ø130
Speed rotate speed	8000rpm
X.Y.Z axis ball screw specifications	4012
X.Y.Z shaft moving speed(m/min)	24,24,18
X axis rail specifications	MSA35LA
Y axis rail specifications	MSA35LA
Z axis guide ways	sliding guide
X.Y.Z motor connection way	Direct connection
Recommend selection of main motor parameters (power KW)	5.5
Recommend choose X.Y.Z axis motor parameters (NM) of torque	8,10,10
Guide way cover bracket (X, Y, Z)	380,303,190
height of Lathe bed pad	30
Max loading of worktable kg	350 Kg
machine net weight	4t
Note	“Type column
