BT 30 5.5KW Spindle ATC Motor With Key Ways for Cnc Spindle for Milling
US$ 2,500 - 2,690
MOQ: 2 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HNZ
Model Number:
BT 30 5.5KW
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO PORT
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ATC bt 30 5.5kw Atc Spindle Motor With Key WaysUS$ 2,205 - 2,255MOQ: 1 Set -
Milling Spindle Belt Drive Spindle BT30-100mm Cnc Belt Driven SpindleUS$ 837 - 850MOQ: 5 Sets
-
90HZ08-5.5KW-11 Spindle BT 30 Cnc Belt Drive Spindle for Cnc Machine CenterUS$ 840 - 860MOQ: 5 Sets
-
Belt Drive Cnc Milling bt 40 ATC CNC Spindle 5 .5KW-11kw BT 40 120mm Diameter for Cnc Machine CenterUS$ 1,375 - 1,400MOQ: 5 Sets
-
3.0k Spindle Motor Used in Wood Carving MachineUS$ 226 - 265MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
HNZ
Model Number
BT 30 5.5KW
Application
Grinding
Maximum Torque
4.37
Drive
Motor
Operating Speed
12000RPM
Specifications
1)5.5kw Spindle(2)12000 r/m,140D 600hz
(3) Cooled by water
(4) Used in cnc machine (5) 6 poles spindle
BT 30 5.5KW spindle ATC motor with key ways for cnc spindle for milling
Brand name: Haina
Spindle type: 140-HNZ5.5
Power: 5.5KW
Joint of Nose: BT30
Noise:66db
Voltage: 380v
Shocking:0.5μm
Current: 15A
Diameter:140mm
Length:416mm
Cooling:water cooling
Speed: 3000-12000rpm
Temperature control:18°C
Frenquency: 600Hz
Torque: 3.6N.m-18Nm
Bearings:7010*4 7008*2
