Automatic Pet Food Packing Machine

Specifications

Automatic Pet Food Packing Machine:
1.Suit for packing food hardware
2.High precision and capacity
3.Easy operation

Application: Granule products ,foods & non-foods, such as pasta,chips, candy, medicine tablet, powder, meat,vegetables,fruits pieces,sugar ,oatmeal, metal pieces etc.



Features:

* Attractive standing bag style to satisfy the market demand.

* It completes bagging, sealing, date printing, punching, bottom flat automatically;

* Film pulling down system controlled by servo motor, with film deviation control;

* Famous brand PLC. Pneumatic system for vertical and horizontal sealing;

* Easy to operate, low maintenance, compatible with different internal or external measuring device.

* The way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements.



Specification:



Model	VS-520	VS-720
Capacity	Max 40bags/min	Max 40bags/min
Bag size	Front width:70--180mm	Front width:100--240mm
	Side width:40--100mm	Side width:50--120mm
	Width of side seal:5--10mm	Width of side seal:5--10mm
	Length:100---320mm	Length:100---420mm
Bag type	Block bottom standing bag	Block bottom standing bag
Film width	Max 500mm	Max 700mm
Air consumption	0.8Mpa 0.30m3/min	0.8Mpa 0.30m3/min
Power supply	220V  3.5KW  50HZ	220V  4KW  50HZ
