Auto Vertical Form Fill Seal Packing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
Used
Year:
2011
Power:
3.5KW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shunde China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Liquid Packing Machine For Lotus-bean PasteNegotiableMOQ: 1 Set -
High-Performance Packing Machine For 4-sides SealingNegotiableMOQ: 1 Set
-
Perfume Filling Sealing and Packing MachineNegotiableMOQ: 1 Set
-
Salt and Seed Packaging MachineNegotiableMOQ: 1 Set
-
Blister Packing MachineNegotiableMOQ: 1 Set
Condition
Used
Year
2011
Power
3.5KW
Place of Origin
Guangdong, China
Brand Name
VANWELL
Model Number
VL-600
Application
Other, Food and non-food
Driven Type
Other, electric
Packaging Material
Other, plywood
Packaging Type
Other, plywood case
Automatic Grade
Automatic
Specifications
Auto Vertical form fill seal packing machineSuitable for automatic packaging of loose, non adhesive , granule products.
The Vanwell VL600 model is servo driven and equipped with PLC and colour touch screen. The system enables the operator, via a user-friendly interface, to enter machine parameters as well as access the machine status and operating conditions.
- Servo-driven, intermittent motion end seal jaws.
- User-friendly PLC and touch screen operation interface allowing for multilingual operation and access restriction features.
- Comprehensive synchronisation for date printer and feeding systems.
- Simple and fast bag size changeover with one-piece forming sets.
- Jam detection/ alert to prevent product jam between the sealing jaws
- Photocell for centring printing.
- Completely outfitted with Stainless Steel in order to provide durability as well as sanitation.
- Every unit comes equipped with hot foil printer
The various packaging applications include
- Free Flow Powders: Sugar, Salt, Pepper, Spices, Flour, Semolina, Milk powder, various sorts of powders, etc. [non-food: detergents, plaster, talc, chemical additives.
- Granules & Seeds: Coffee beans, Cocoa, Rice, Sesame, Seeds, Small Granules etc.
- Dry, Frozen & Processed Foods: Snack foods [popcorn/chips], Cereal & Health Foods,
- Confectionary, Biscuits & Bakery, Pasta, Grated Cheese, Nuts, Dried fruits and vegetables, Frozen Vegetables, Dried Mushrooms, Pet Food.
- Fresh Foods: Fresh Produce
- Non Food: Medium- Nuts, Small metal/plastic items, Bolts, Washers, Auto, Electrical and Plumbing Parts etc.
- Basic technical specifications FOCUS FM-520
Available dosing systems l Auger doserBag size:L=100-390mm, W=75-245mmPacking range:15-1000g (depending on the materials)Fill roll:Laminated Film [OPP/CPP, OPP/PE, MST/PE, PET/PE, N/PE, OPP/EVA, EVA/PE]Thickness:0.04-0.08mmMax. output/ speed:40-100 bag/min depending on bag length, output of used dosing device, product character, dosing size and required dosing accuracy.Electricity Consumption:220 V, 50 Hz, 3.5KWAir Consumption:6kg/cm, 0.25m3/minWeight:600kgMachine dimensions:1400mm x 1500mm x 2100mm (L x W x H)l (Volumetric) Cup fillerl Multihead weigherl Linear weigherl Liquid doserUsable types of packaging materialsThe VL600 machine is equipped with thermal jaws enabling the use of all standard thermal weldable materials, such as:
- Laminated Al foil with polyethylene
- Paper laminated with polyethylene
- Polypropylene film
- As well as a number of special films [e.g. monolayer film]
OptionalOperating speedSynchronically with the VL600Printer methodHot-die stamping with airPrinter typeHot foil printerPrinting area3 lines, (W) 35 mm x (L) 10 mmCharacters per lineMax. 12 charactersPrinting positionAdjustableOptional accessories are deliverable upon customer request- Gas Flushing (Air or Nitrogen gas)
- Tear Notch
- Gusseted/Blockbottom Tooling
- Hole Punch Device
- Material Stopper
- Bag Support
- Polyethylene Sealing System
- Vacuum bag System
