Help CenterFST CNC-20 F Series Precision CNC Longitudinal Turning and Milling Machine
Related Products
-
High Precison NC0625D CNC Lathes for Turning and MillingUS$ 13,700 - 14,000MOQ: 1 Set -
High Precison NC0625CNC Lathes for Turning and MillingUS$ 13,900 - 14,100MOQ: 1 Set
-
NC0620D Servo CNC Lathes for Turning and MillingUS$ 8,900 - 9,500MOQ: 1 Set
-
5-axis (X,Y,Z,C,G) Swiss Type Cnc Lathe and Cnc Milling Machine for Watch 20F TypeUS$ 32,500 - 33,000MOQ: 1 Set
-
High Precision NC0620 Servo CNC LathesUS$ 8,000 - 8,500MOQ: 1 Set
Specifications
Brand:HNZTotal power:6KW
Spindle speed: 200-10000r/min
Spindle rotatable Infinitely variable
Spindle motor power 3KW
Parts |
Type Items |
CNC-20F |
Main Parameter |
Maximum diameter of processing the bar |
Φ20 |
Maximum length of processing parts |
170 |
|
Maximum drilling diameter |
Φ6 / Φ8 |
|
Maximum axial tapping screw |
M6/CU M8 / M6/CU M10 |
|
Total power |
6KW |
|
Spindle Parameter |
Spindle speed range |
200-10000r/min |
Spindle rotatable |
Infinitely variable |
|
Height from Spindle center to table |
950mm |
|
Spindle motor power |
3KW |
|
|
Feed section Parameter |
X-axis screw specifications |
1605 |
Y / Z axis screw specifications |
2010 |
|
X / Y axis rails Specifications |
20 |
|
Z axis rails Specifications |
25 |
|
|
X(with holding brake),Y,Z axis Servo motor rated torque
|
0.75kw |
|
Toolholder Partial Parameters |
External Turning Tool |
5 pieces |
External Turning Tool Specifications |
10×10×120 |
|
Non-rotating hole processing tool |
ER16(4 pieces) |
|
Lateral rotary power tool |
ER16(4 pieces) |
|
Dynamic milling head Power |
0.4KW |
|
Dynamic milling head SpeedRange |
50-4000(Servo) |
|
Others |
Lubrication pump power |
25W |
Cooling system motor power |
0.25KW |
|
Size |
Machine outer size diameter (length*width*heigth) |
1380×840×1480 |
Weight |
Net weight |
About 1670 kg |
Characteristic:
1 high efficiency,reasonable structure
2 three axis all adopt linear ball guide,long time using,high precision, driven by Yasukaawa servo motor
3 Taiwan SYNTEC control system ,simple operation,complex shape parts production,such as micro shaft,electronic connectors,optical clocks and various hardware and other small accessories
4 more Cutter number, quick knife change
