industrial Powder mixing machine ( ribbon type)
Horizontal ribbon mixer is a new type of mixing equipment with high efficiency, high uniformity, high load factor, low energy consumption, low pollution and little destruction to frangible material. It is widely used to mix powder-powder and powder-liquid, especially materials that are paste, viscous or with big specific gravity such as putty, stone coatings, metal powders etc. It is currently applied in industries of pharmacy, food, pesticides, dyes, chemicals, plastics, ceramics, paint, putty, mortar etc.
Main Features
Stainless steel wetted parts (carbon steel also available)
Material charging port with grid for safety
Discharge port at the centre
Safety limit switches to prevent operation when covers are raised
Outside painted with epoxy coating
Single speed drive
Technical Parameters
Model |
Power |
Rotation |
Mixing |
Dimension |
Weight |
SLD-0.3 |
5.5 |
41 |
90-210 |
1900*600*950 |
780 |
SLD -0.5 |
7.5 |
41 |
150-350 |
2500*780*1150 |
1000 |
SLD -1 |
11 |
33 |
300-700 |
2700*980*1450 |
1800 |
SLD -2 |
15 |
33 |
600-1400 |
3200*1200*1700 |
2300 |
SLD -3 |
18.5 |
33 |
900-2100 |
3500*1450*1950 |
3200 |
SLD -4 |
22 |
22 |
1200-2800 |
4100*1400*2000 |
4000 |
SLD -5 |
30 |
22 |
1500-3500 |
4400*1500*2150 |
4800 |
SLD -6 |
37 |
22 |
1800-4200 |
4750*1560*2200 |
6300 |
SLD -8 |
45 |
22 |
2400-5600 |
4900*1750*2450 |
8500 |
SLD -10 |
55 |
19 |
3000-7000 |
5650*1750*2450 |
9500 |
SLD -15 |
90 |
17 |
4500-10500 |
5850*2000*2900 |
11000 |
SLD -20 |
110 |
11 |
6000-12000 |
6050*2650*3150 |
13500 |
*Calculated as per water as medium
**Dependent on material viscosity
Options
Drive type: Coupled type or divided type (belt/chain)
Agitator type: Dual-direction continuous ribbon, single direction continuous ribbon
Wetted parts of carbon steel Q235, stainless steel SUS316 and SUS304
Opening of cylinder: Standard flange, quick opening charge port, dust collector port, manual
Main shaft Sealing: Packing seal, packing seal & gas seal, mechanical seal
Discharge mode: Manual, electric or pneumatic
Discharge valve: Butterfly valve, ball valve, plum valve or flap valve
Jackets for heating or cooling
Vacuum or pressure construction
Sanitary type construction
Explosion-proof
Cleaning door, sampling port
Spray nozzles for liquid introduction
Dust collector
Applications
Dye, pigment, Food, Construction materials, Pesticides, Lithium battery mate, Hard materials, Ceramics etc
Custom designs are also available.
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
