Gypsum dule shaft mixer
Horizontal non-gravity mixer is a Korean-technical late-model mixing equipment with high efficiency, high uniformity, high loading coefficient but low energy cost, low pollution and low crush. Agitators, designed in special angle, rotates in same but opposite direction and shows a nice mixing, smashing, dispersing results. It is widely used in powder-powder, powder-liquid, powder-particles mixing. It is also able to used for materials in different specific gravity and particles in a wide range of sizes.
Rich Experience & Excellent Design Aptitude
Products are designed according to the characteristic of raw and finial products materials and manufacturing process(i.e. Pressure requirement, proportion of solid and liquid) to meet the requirements in driving device, operability, leak-proofness and etc. areas.
Reliable Driving Device
Different driving devices in various capacity, power and output speed are in option according to the materials, starting methods and mixing method.
Driving motor uses SIEMENS, ABB, SEW and etc international brands products, output torque can be output by direct-combination, chain-wheel combination, hydraulic couplers and etc.
Reducers uses R series umbrella gear reducer ( or K series spiral cone gear reducer) with high usage coefficient, large rated torque, high conveying rate, safe, long service life, low noisy, low risk of failure, easy to maintenance and etc advantages.
High Efficient Mixing Device
Multi-experiments and design for the angle and cross area of blades contributes to a reasonable agitator with high efficient.
Different surface treatments are in option to strength the blade in hardness or wear-resisting to meet high requirements of hard materials. Surface treatment includes surface carburizing/nitriding, heat treatment, tungsten carbide spray, etc.
Adjustable extension blades are in option, which is easy to change or decrease the gap between the blades and cylinder. It is good for wording condition with large wear.
Nice Assistant Component
Assistant components are in option, such as: coil steam heating jacket, honeycomb anti-pressure jacket, recycle-medium jacket, real-time sampling valve, high speed fly-cutter, temperature detector, weighting system, dust collecting system, vacuum drying system and etc.
Spray and atomizing device are in option to spray little liquid which will mix the liquid into powders better. Spraying system consists of pressure source, liquid storage tank, spray device.
Cylinders can be designed in carbon steel, SS304, SS316L, SS321, other harder alloy can also be used on agitator. Lining of cylinder can be polyurethane or spraying wear-resistant material.
Model |
Power (kw) |
Speed (rpm) |
Thickness (mm) |
Capacity (L) |
Size(mm) |
||
Length |
Width |
Height |
|||||
SWZL-0.1 |
3 |
60 |
4 |
30~60 |
1000 |
1000 |
1000 |
SWZL-0.2 |
4 |
60 |
4 |
60~120 |
1100 |
1100 |
1100 |
SWZL-0.5 |
7.5 |
43 |
5 |
150~300 |
1500 |
1500 |
1100 |
SWZL-1 |
11 |
43 |
5 |
300~600 |
1750 |
1750 |
1500 |
SWZL-2 |
15 |
40 |
5 |
600~1200 |
2200 |
2500 |
1800 |
SWZL-3 |
18.5 |
35 |
5 |
900-1800 |
2300 |
2650 |
1800 |
SWZL-4 |
22 |
35 |
6 |
1200-2400 |
2500 |
2900 |
2300 |
SWZL-6 |
37 |
33 |
6 |
1800-3600 |
2800 |
3000 |
2400 |
SWZL-8 |
45 |
33 |
6 |
2400-4800 |
2800 |
3500 |
2550 |
SWZL-10 |
55 |
26 |
8 |
3000-6000 |
3050 |
3700 |
2700 |
SWZL-15 |
75 |
22 |
8 |
4500-9000 |
3200 |
4250 |
2900 |
SWZL-20 |
90 |
18 |
8 |
6000-12000 |
3500 |
4700 |
3300 |
Please contact with us or check our webisite for more detailed information.
