Powerful dual planetary mixer | Potting adhesive mixer
Powerful Dual Planetary Mixer is a new mixing machine with high performance, high efficiency, easy to clean and to maintain, which
is innovated and improved based on dual planetary mixer. The Double agitators of this equipment rotate and at the same time revolve
around the axle, the agitators are divided by the viscosity and characteristics of the material, usually include paddle type, twist type,
claw type, frame type etc., have good mixing, reacting, kneading, dissolving effect. The high-speed disperser consists of multi-layer toothed disc with super high linear speed, it also rotates and at the same time revolve around the axle, with strong dispersing
effect so that can disperse the powder (additive) in the liquid rapidly. The mixer is equipped with a separate set of scraper to scrape
the sides of the barrel and the mixing paddle can be added a scraper as well, so that it can scrape the bottom of the barrel and avoid
dead corner to ensure the stability of the product. Double Planetary Mixer adopts planetary gear wheel drive, there is a large output
torque, suitable for high temperature, high solids, high viscosity, and other difficult working conditions; this equipment is closed design,
can be used with a vacuum system to realize vacuum mixing, mixing bucket can be designed with a heating jacket, matching mold
temperature controller, to realize thermostatic mixing function,it’s the first choice of mixing machine for the highviscosity materials.
[Production Capacity]: 5-2000L
[Applicable Materials]: Various slurry with viscosity less than 3,000,000cps, solid content under 90% such as battery paste, solder
paste, ceramic paste, silicone inks, sealants, structural adhesives, soft cream, jam etc..
Model |
Work volume (L) |
Mixing power (kw) |
Revolving speed (rpm) |
Rotating speed (rpm) |
Scraper speed (rpm) |
Dispersing power (kw) |
Dispersing speed (rpm) |
Lift (mm) |
Hydraulic power (kw) |
Vacuum pump power (kw) |
SDJB-8 |
5 |
1.5 |
0-65 |
0-170 |
0-170 |
1.5 |
0-2930 |
300 |
0.75 |
0.37 |
SDJB-15 |
12 |
2.2 |
0-65 |
0-170 |
0-170 |
3 |
0-2930 |
350 |
0.75 |
0.55 |
SDJB-30 |
24 |
4 |
0-65 |
0-170 |
0-170 |
5.5 |
0-2930 |
500 |
1.1 |
1.5 |
SDJB-50 |
40 |
5.5 |
0-65 |
0-170 |
0-170 |
7.5 |
0-1450 |
500 |
1.1 |
1.5 |
SDJB-100 |
80 |
7.5 |
0-30 |
0-95 |
0-95 |
11 |
0-1450 |
650 |
1.5 |
2.2 |
SDJB-200 |
160 |
11 |
0-30 |
0-95 |
0-95 |
15 |
0-1450 |
750 |
2.2 |
2.2 |
SDJB-300 |
240 |
15 |
0-30 |
0-95 |
0-95 |
18.5 |
0-1450 |
900 |
3 |
4 |
SDJB-500 |
400 |
22 |
0-30 |
0-65 |
0-65 |
30 |
0-1450 |
1000 |
4 |
4 |
SDJB-800 |
640 |
30 |
0-30 |
0-65 |
0-65 |
37 |
0-1450 |
1100 |
4 |
5.5 |
SDJB-1000 |
800 |
37 |
0-30 |
0-65 |
0-65 |
45 |
0-1100 |
1200 |
5.5 |
7.5 |
SDJB-1200 |
960 |
45 |
0-30 |
0-65 |
0-65 |
55 |
0-1100 |
1300 |
5.5 |
11 |
SDJB-1500 |
1200 |
55 |
0-30 |
0-65 |
0-65 |
75 |
0-960 |
1400 |
7.5 |
11 |
SDJB-2000 |
1600 |
75 |
0-30 |
0-65 |
0-65 |
90 |
0-960 |
1500 |
11 |
15 |
Remark:
*Capacity is tested based on the materials viscosity 200,000cps; The model selection shall be based on the data such as the
materials viscosity, characteristic etc.
* If the working condition is high temperature, high pressure, flammable, explosive, corrosive or others, you must provide detailed
data for our engineer to customize specially.
* If any change in the above table, subject shall prevail without notice.
* The table cannot include all products, please contact with our sales engineers for more information.
SIEHE Industry------expert on manufacturing and sales of liquid and powder equipment!
QQ: 2880860650
Skype: Polinder800
Tel:021-52913185-114
Phone: +86-18916519796
