Dual shaft high speed mixer
Overview
Dual Shaft MultiFunctional Strong Power Dispersing Mixer is a new developed powerful dispersing and mixing machine base on hydraulic lifting single shaft mixer, it can be divided into dispensable dual shaft and coaxial dual shaft according to the dual shaft coaxial or not; this machine is specially suitable for mid-and-high viscosity material and thixotropic material, many agitator patterns for option, usually has anchor type, butterfly type, frame type etc., can disperse and mix at the same time, with strong adaptability, can be customized according to different property and production process of the material.
Specifications
Model |
Dispersing power (kw) |
Dispersing speed (rpm) |
Mixing power (kw) |
Mixing speed (rpm) |
Material |
Capacity (L) |
Hydraulic power (kw) |
Lifting (mm) |
SYZ-100 |
5.5 |
0-2880rpm |
2.2 |
0-85rpm |
Material contacting part SS304 |
≤80 |
1.1 |
700 |
SYZ-200 |
7.5 |
0-1450rpm |
4 |
0-85rpm |
Material contacting part SS304 |
≤160 |
1.5 |
800 |
SYZ-300 |
11 |
0-1450rpm |
7.5 |
0-61rpm |
Material contacting part SS304 |
≤240 |
1.5 |
900 |
SYZ-500 |
18.5 |
0-1450rpm |
11 |
0-61rpm |
Material contacting part SS304 |
≤400 |
2.2 |
1000 |
SYZ-800 |
30 |
0-1450rpm |
18.5 |
0-52rpm |
Material contacting part SS304 |
≤640 |
4 |
1100 |
SYZ-1000 |
37 |
0-1450rpm |
22 |
0-52rpm |
Material contacting part SS304 |
≤800 |
5.5 |
1200 |
SYZ-1300 |
45 |
0-1450rpm |
30 |
0-52rpm |
Material contacting part SS304 |
≤1000 |
5.5 |
1300 |
SYZ-1500 |
55 |
0-1450rpm |
37 |
0-41rpm |
Material contacting part SS304 |
≤1300 |
5.5 |
1400 |
SYZ-2000 |
75 |
0-1450rpm |
45 |
0-41rpm |
Material contacting part SS304 |
≤1600 |
7.5 |
1600 |
WHY US
High mixing efficiency, good quality
Dual Shaft MultiFunctional Strong Power Dispersing Mixer consists of the agitator with scraper and high speed disperser, two sets of agitators working at the same time, so that the materials are mixed rapidly under the action of strong shearing and kneading force. Various agitators ( usually anchor type, butterfly type etc) are in option based on materials with different viscosity and different specific gravity and different production technology.
Safe and convenient operation
Adopt hydraulic cylinder as lifting actuators. Control the mixer up, stop and down through controlling the valve, simple operation with high stability; with bolt for fixing the agitator and the main shaft, easy to disassemble and to clean. Different clamping mode (belt clamping, manual rotation clamping, pneumatic clamping) are optional for fixing the mixing tank rapidly to prevent any possible accident due to tank displacement. .
- No residue on the wall, clean discharging
There is scraper on the agitator, it clings to the container and scrape the materials on the wall off continuously. The container inner wall is precisely lathed and then mirror polished to ensure the scraper can scrape all materials sticking to the wall off without residue, improving the mixing effect..Customized options
- Customized options
