Industrial multi-function blending tank
Mixing kettle, which is used for liquid-liquid or powder-liquid blending and mixing, is a type of large-scale production equipment and has the functions of dispersing, emulsifying, heating and cooling, to fulfill different production process requirement; It can be stably running for long time, has the advantages of small noise, simple operation and strong adaptability, is the ideal multi-functional equipment for mixing and dispersing.
High Mixing Efficiency & High Quality
Siehe Industry has many years’ experience of mixing kettle application, capable to select the most suitable agitator and speed according to different materials feature and mixing requirements, thus the liquids will be mixed in cross and turbulent flow, and at the same in axial and radial motion, finally get uniformly mixed after a certain period of time.
High-speed Dispersing and Emulsifying, Fulfill More Demands, Cost-effective
Mixing kettle can be equipped with 1-2 high-speed disperser and emulsifier with the highest speed 2930rpm(normally 1450rpm), velocity above 20m/s, which make sure the powder material can be uniformly dispersed into the liquids; the mixture will be finally dispersed uniformly and shows good suspension effect because of high-shearing force.
Easy Maintenance and Cleaning
The agitator is fixed on the shaft via bolts, easy to remove and disassemble.
Non-standard
Variety of models can be customized, e.g. explosion proof model, vacuum model, scraper model, multi-function model, etc. The equipment material can adopt SS316L or do spray-coating treatment according to client’s requirement.
Model |
Power(kw) |
Speed |
Agitator |
Equipment Material |
Capacity(L) |
Weight |
SJBF-1.1 |
1.1 |
100rpm |
Anchor type, paddle type, frame type and other types of agitators don’t share the same data regarding the viscosity application, speed, power, etc. |
Contact part SS304 |
≤200 |
250 |
SJBF-1.5 |
1.5 |
85rpm |
Contact part SS304 |
≤300 |
250 |
|
SJBF-2.2 |
2.2 |
76rpm |
Contact part SS304 |
≤500 |
300 |
|
SJBF-3.0 |
3.0 |
67rpm |
Contact part SS304 |
≤800 |
350 |
|
SJBF-4.0 |
4.0 |
63rpm |
Contact part SS304 |
≤1000 |
450 |
|
SJBF-5.5 |
5.5 |
59rpm |
Contact part SS304 |
≤1500 |
350 |
|
SJBF-7.5 |
7.5 |
59rpm |
Contact part SS304 |
≤2500 |
450 |
|
SJBF-11 |
11 |
53rpm |
Contact part SS304 |
≤3000 |
350 |
|
SJBF-15 |
15 |
53rpm |
Contact part SS304 |
≤4000 |
450 |
|
SJBF-18.5 |
18.5 |
53rpm |
Contact part SS304 |
≤5000 |
350 |
|
SJBF-22 |
22 |
43rpm |
Contact part SS304 |
≤8000 |
450 |
|
SJBF-30 |
30 |
43rpm |
Contact part SS304 |
≤10000 |
350 |
|
SJBF-200 |
200 |
Non-standard |
Non-standard |
Contact part SS304 |
non standard |
non standard |
Please contact with us or check our webisite for more models.
