Mixing Kettle
Product Description
Main Features:
- SIEHE company provides various resin reaction kettles, with full range from lab one to production one. It can be customized designed and manufactured to meet different resin production requirements.
- Reaction Kettle consists of components such as kettle body, kettle cover, jacket, agitator, driving device, shaft sealing device, support etc..
- Various seals (packing seal, mechanical seal, magnetic seal) are available according to different requirements of mixing processing.
- Regular agitators: anchor type, impeller type, turbine type, propeller type or frame type etc.. If the height and diameter of the kettle are comparatively big, then multi-layers propeller is advisable. Agitators can also be selected and designed according to production processing. When the resin viscosity or the viscosity during reaction comes up to more than 300000cp, it has especially high requirements about mixing equipment. SIEHE company has rich experiences in mixing high-viscous mateirals. Welcome to consult with our sales engineers.
- Support seat: ground type or platform lug type.
- SIEHE company is familiar with resin (especially SMC,BMC resins) reaction and has rich application experience.
Technical Parameter:
Capacity: 10-20000L
Materials: the part contacting material can be SS304, SS316L, SS321, Q235
Heating method: electric heating, steam heating, hot water heating, heat transfer oil circulation heating, far-infrared heating etc..
Cooling method: jacket cooling, interior and exterior limpet coil cooling.
Seal: Mechanical Seal, Packing Seal, Hermetic Seal, Rubber Lip Seal, Magnetic Sea
Environment Requirements: Explosive-proof or non explosive-proof
