Semi Automatic High Viscosity Adhesive Filling Machine

Semi Automatic High Viscosity Adhesive Filling Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Medical, Other, Chemical, Medical, Coating, paint, adhesive etc
Packaging Type:
Barrel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Chemical, Medical, Other, Chemical, Medical, Coating, paint, adhesive etc
Packaging Type Barrel
Packaging Material Metal, Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 380V, can be customized
Power 50/60 HZ
Place of Origin Shanghai, China
Brand Name SIEHE
Model Number SGZ Series
Certification CE, BV, ISO, SGS
After-sales Service Provided Engineers available to service machinery overseas

Semi automatic high viscosity adhesive filling machine



Semi automatic high viscosity adhesive filling machine



Product Introduction:

High Viscosity Semi-automatic Filling Machine adopts gravimetric method to measure, by screw extruder or high viscosity convey pump (such as screw pump, rotor pump) for feeding, conveying device with the function of frequency speed control can realize quick or slow feeding. Weighing sensor output signal control screw and the discharge of the pump (fast, slow, or stop feeding) to achieve automatic filling. The filter device can be added before filling to guarantee the quality of products. The machine is the dedicated filling machine SIEHE Industry developed for processing high viscosity product.



[Materials Viscosity]: ≤500,000 cps



[Production Capacity]: 5-50kg



[Application Industry]: Suitable for filling of various high viscosity materials such as ink, adhesive, chemical, cosmetic, food, medicine, etc..



[Applicable Materials]: Materials shall be with viscosity less than500,000cps, liquid or slurry with a certain liquidity such as putty, stone coating, ointment, adhesive, AB glue, neoprene adhesive, epoxy adhesive, skin ointment, hair dye, shoe polish, tooth paste, etc..



Technical Parameter:

Power Voltage: 380V

Air Pressure: 4kg/cm²

Production Capacity: 2~4 barrels & bags/min

Filling Volume: 5-50kg

Filling Accuracy: ±0.2%

Material: material contacting part SS304 stainless steel
