Help CenterOil High-shear Emulsifier(Hydraulic Lifting)
Related Products
Oil High Shear Homogenizer (Hydraulic Lifting)
Wide usage;
Good configuration;
Excellent emulsifying effect.
1. Reference Parameter
Power Supply: 380V, 50/60Hz(Can be customized).
Speed Adjustment: Frequency Converter.
Materials: The part contacting with materials is SS304 or SS316L.
Model |
Capacity (L) |
Motor (kw) |
Speed (rpm) |
Lit (mm) |
SRH -4 |
≤400 |
4 |
0-2930 |
800 |
SRH -7.5 |
≤800 |
7.5 |
0-2930 |
900 |
SRH -11 |
≤1000 |
11 |
0-2930 |
900 |
SRH -15 |
≤1200 |
15 |
0-2930/1450 |
900 |
SRH -18.5 |
≤1500 |
18.5 |
0-2930/1450 |
1100 |
SRH -22 |
≤2000 |
22 |
0-2930/1450 |
1100 |
SRH -30 |
≤2500 |
30 |
0-1450 |
1100 |
SRH -37 |
≤3000 |
37 |
0-1450 |
1600 |
SRH -45 |
≤4000 |
45 |
0-1450 |
1600 |
SRH -55 |
≤5000 |
55 |
0-1450 |
1600 |
SRH -75 |
≤6000 |
75 |
0-1450 |
1800 |
2. Main Features
a. Claw shaped workhead (Dual direction suction) is stainless steel precision forged.
b. Good gap fitness and high tip speed ensure excellent emulsifying and homogenizing effect. c. All components are processed by the imported CNC and throgh dynamic and static balance test to ensure the stable and safe operation of the equipment.
d. Hydraulic Lifting Stand is stable and flexible.
e. The whole machine looks nice and operates easily.
Remarks:
*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object
*Not all products are listed. For more, please contact with our sales engineer
SIEHE Industry----Mixing Experts on Liquid and Powder!
Please feel free to contact us for more details:
Tel: +86 21 52913185 ext 113
Fax: +86 21 52912822
Email: sales04 at
Skype: siehe.sales10
