---Solutions to doubts
would you like to recycle waste tire?
would you like to get pure rubber for making rubber products?
would you like to get rubber from waste tire within lowest cost and consuming?
now our machine can help you do it.
---Brief introdution
such semi-automatically machine is to recycle different types tire(radial tire,nylon tire) into rubber powder(30-100mesh)free of steel and fiber.
ring cutter-strips cutter-blocks cutter-bead wire separator-XKPseries crusher-shaking screen-conveyor-steel magnetic separating conveyor-fiber separator
Specification:
ring cutter is used for cutting the used tire into three parts,two sidewalls and one tread.
| model |
motor (kw) |
processing range(mm) |
weight (kg) |
dimension (mm) |
production |
| QKF850 | 2.2 | 750-1200 | 300 | 1300*900*1480 | 2ton tire/h |
Specifications:
strips cutter is used for cutting the sidewalls and tread into rubber strips.
| model |
motor (kw) |
processing range (mm) |
weight (kg) |
dimension (mm) |
production |
| QT380 | 4 | 750-1200 | 900 | 1300*750*1580 | 1ton/hour |
Specifications:
blocks cutter is used for cutting rubber strips into rubber blocks.
| model | motor(kw) | processing range(mm) | weight(kg) | dimension(mm) | production |
| QK200 | 7.5 | 750-1200 | 450 | 800*810*1070 | 1ton/hour |
Specifications:
bead wire separator is to separate the whole steel circle from bead.
| model | motor(kw) | Processing range | Weight(kg) | Dimension(mm) | production |
| GF240 | 15 | bead tire | 1800 |
1520*1180*122
|
30pieces tire/hour |
Specifications:
rubber powder producing plant(xkp series) is to crush rubber blocks into rubber powder(0.6-3mm)
Type |
diameter of rollers *length(mm) |
speed ratio of rollers |
max distance of two rollers (mm) |
motor power (kw) |
dimensions (mm) |
weight (kg) |
|
XKP400 |
400*600 |
1:1.38 |
10 |
45 |
4210*1850*1925 |
7500 |
|
XKP450 |
450*760 |
1:1.38 |
10 | 55 |
4550*1970*1860 |
11000 |
|
XKP560 |
560*800 |
1:1.38 |
15 | 90 |
5620*2260*1900 |
17000 |
| XKP610 | 610*800 | 1:2 | 16 | 132 | 5739*2270*1560 | 17500 |
Specifications:
fiber separato is to separate the fiber from 20-24mesh rubber powder.
| Model | Motor(kw) | weight(kg) | processing range |
dimension (mm) |
production |
| KF1200 | 6.25 | 1800 | rubber powder | 1460*1500*4200 | 500kg/h |
---Output got from such plant,
---About Xinyutian factory
Xinxiang Xinyutian Rubber&Plastic Machinery Co.,ltd locates in the important industry area of Yubei.Our enterprise is dedicated to research and develop tire recycling rubber powder plant.our machines have been sold all over the world,what is more,we got great feedback from our customers in Asia,Central Asia,North Europe and South America.
----delivery details
---Welcome inquiry from overseas friends,Contact us at any time!
Tel:+86(0)373 3033288 Fax: +86(0)373 3692059
mobile:+86 15936531984 skype:wjangelabaibai
Address:Xinpu Road,Xinxiang City,Henan Pro.China
