Brief introdution of xkp series!crumb rubber plant,
Specification:
xkp series!crumb rubber plant (ring cutting machine) is used for cutting used tyre into three parts,two sidewalls and one tread.
Main parameters:
| model |
motor (kw) |
processing range(mm) |
weight (kg) |
dimension (mm) |
production |
| QKF850 | 2.2 | 750-1200 | about300 | 1300*900*1480 | 2ton tire/h |
Specifications:
xkp series!crumb rubber plant (cutting strips machine) is used for cutting the sidewalls and tread into rubber strips.
Main parameters:
| model |
motor (kw) |
processing range (mm) |
weight (kg) |
dimension (mm) |
production |
| QT380 | 4 | 750-1200 | 900 | 1300*750*1580 | 1ton/hour |
Specifications:
xkp series!crumb rubber plant (cutting blocks machine) is used for cutting rubber strips into rubber blocks.
Main parameter:
| model | motor(kw) | processing range(mm) | weight(kg) | dimension(mm) | production |
| QK200 | 7.5 | 750-1200 | 450 | 800*810*1070 | 1ton/hour |
Specifications:
xkp series!crumb rubber plant (steel separator) is to separate the whole steel circle from bead.
Main parameter:
| model | motor(kw) | Processing range | Weight(kg) | Dimension(mm) | production |
| GF240 | 15 | bead tire | 1800 |
1520*1180*122
|
30pieces/hour |
Specifications:
xkp series!crumb rubber plant (xkp series) is to crush rubber blocks into rubber powder(0.6-3mm)
Main parameter:
Type |
diameter of rollers *length(mm) |
speed ratio of rollers |
the biggest distance of two rollers (mm) |
numbers of revolutions |
motor power(kw) |
dimensions (mm) |
weight(kg) |
| XKP400 |
400*600 |
1:1.38 |
10 | 13.65 |
45 |
4210*1850*1925 |
7500 |
| XKP450 |
450*760 |
1:1.38 |
10 | 16.57 |
55 | 4550*1970*1860 |
11000 |
| XKP560 |
560*800 |
1:1.38 |
15 | 15.5 |
75 | 5620*2260*1900 |
19000 |
Specifications:
xkp series!crumb rubber plant (fiber separator) is to separate the fiber from 20-24mesh rubber powder.
Main parameter:
| Model | Motor(kw) | weight(kg) | processing range | dimension(mm) | production |
| KF1200 | 6.25 | 1800kg | rubber powder | 1460*1500*4200 | 500kg/h |
About Xinyutian
Xinxiang Xinyutian Rubber&Plastic Machinery Co.,ltd locates in the important industry area of Yubei.Our enterprise is dedicated to research and develop waste tire recycling equipments that have been sold all over the world.what is more,we got great feedback from our customers in Asia,Central Asia,North Europe and South America.
Advantages of Xinyutian
- special manufacturer that has professional producing team and technical support
- top level sale teams to communicate with clients by email,telephone,face to face.
- professional explanation to clients about machines(techonogy,apply,using guide and so on)
- best after sale---follow the whole producing situation,provide photos of machines loaded into containers, track the operating and using situation of client in case of any problems occur.
- reasonable price
- flexible delievery time
- more than 15 years of experience of exporting ability
We have exported tire recycling plant(QKF850,QT380,QK200,GF240,XKPseries,
KF1200) to India,Indonesia,Malaysia,Pakistan,Kwait,Qatar,Saudi
arabia,Iran,Uz,Russia,Mexcio,Brzail,Australia by 40'container,40'HQ,open 40'container.
