YYJ-FPS01 flat panel solar water heater
Characteristics
1. Optional for pressurized and non pressurized
2. Easy installation on the flat roof and sloping roof.
3. Perfect design combined with building.
Material
Inner tank: SUS304 Stainless steel, Thickness :0.4mm for non pressure and 1.2mm for pressurized system
Outer tank: Galvanized Steel, Thickness:0.55mm
Insulation Layer: 50mm to 60mm
Bracket: Galvanized Steel / Aluminium Alloy
Working Principle:
1.when the temperture of the heat collector reaches the set value,the controller shall start the circulation pump automatically.
2.the circulation pump makes heat-conducting liquid circulate automatically.
3.the heat-conducting liquid transters heat to water by the heat exchanger in the water tank.
4.in case the temperature of the circulation pump does not reach the set value,the circulation pump shall be shut automatically.
Parameter Table
Model |
YYJ-FPS01-150L |
YYJ-FPS01-300L |
Dimensions of tank |
Φ480 *1480 |
Φ480*2800 |
Weight |
38kg |
55kg |
Electric Resistance Working Pressure |
1,5kw,220V |
|
In/Outlet |
G 3/4" |
|
Outside Tank Material |
Galvanized Steel |
|
Inside Tank Material |
Stainless Steel SUS304 (0.4mm thickness) |
|
Framce Material |
Polyurethane (thickness 0.5mm thickness) |
|
Flat Panel Collector Quantity |
1 |
2 |
Flat Panel Collector Specification | ||
Flat Panel Solar Collector Dimension |
2000 * 1000 *80mm |
|
Absorber |
Material |
Chrome Panel |
Coating |
Black |
|
Color |
Black |
|
Thickness |
0.12mm |
|
Absorptivity |
90% ±2% |
|
Emittance |
5% ±2% |
|
Pipes |
Material |
TP2 Copper and alumnium |
Welding |
Ultrasonic |
|
Pipe connector |
25mm |
|
Glass |
Material |
textured Tempered Glass with low iron Conetent |
Iron Content |
≤0.01% |
|
Transmittance |
≥92% |
|
Thickness |
3mm |
|
