300L flat panel solar water heater

FOB Price

USD $100 - $2,500 / Set

1 Set(Min.Order)

Product Details

Type:	Flat-Plate	Pressure:	Other, Pressurized, Pressurized or non-preesurized	Circulation Type:	Direct / Open Loop (Active)
Heating System:	Thermosyphon (Passive)	Connection Type:	Direct-Plug	Installation:	Freestanding
Housing Material:	Other, Galvanized Steel	Certification:	CE, CSA, Other, CE, CSA, CCC,ISO900	Capacity:	300, 150-300
Place of Origin:	Zhejiang, China	Brand Name:	EJAI/OEM	Model Number:	YYJ-FPS-01

YYJ-FPS01 flat panel solar water heater

Characteristics

1. Optional for pressurized and non pressurized

2. Easy installation on the flat roof and sloping roof.

3. Perfect design combined with building.

Material

Inner tank: SUS304 Stainless steel, Thickness :0.4mm for non pressure and 1.2mm for pressurized system

Outer tank: Galvanized Steel, Thickness:0.55mm

Insulation Layer: 50mm to 60mm

Bracket: Galvanized Steel / Aluminium Alloy

Working Principle:

1.when the temperture of the heat collector reaches the set value,the controller shall start the circulation pump automatically.

2.the circulation pump makes heat-conducting liquid circulate automatically.

3.the heat-conducting liquid transters heat to water by the heat exchanger in the water tank.

4.in case the temperature of the circulation pump does not reach the set value,the circulation pump shall be shut automatically.

Parameter Table

Model	YYJ-FPS01-150L	YYJ-FPS01-300L
Dimensions of tank	Φ480 *1480	Φ480*2800
Weight	38kg	55kg
Electric Resistance Working Pressure	1,5kw,220V
In/Outlet	G 3/4"
Outside Tank Material	Galvanized Steel
Inside Tank Material	Stainless Steel SUS304 (0.4mm thickness)
Framce Material	Polyurethane (thickness 0.5mm thickness)
Flat Panel Collector Quantity	1	2
Flat Panel Collector Specification
Flat Panel Solar Collector Dimension	2000 * 1000 *80mm
Absorber	Material	Chrome Panel
	Coating	Black
	Color	Black
	Thickness	0.12mm
	Absorptivity	90% ±2%
	Emittance	5% ±2%
Pipes	Material	TP2 Copper and alumnium
Pipes	Welding	Ultrasonic
Pipe connector	25mm
Glass	Material	textured Tempered Glass with low iron Conetent
	Iron Content	≤0.01%
	Transmittance	≥92%
	Thickness	3mm

Company View

Zhejiang Ejai Kitchen&bath Technology Co., Ltd.: Contact nameAdelina Wang; Phone86-573-87656310; AddressNo. 8, Dongxiaoshi Road, Huangwan Town
