Specifications
1. 15 years manufacture experience , free sample
2. CE,Solar key mark,TUV, EN12975-1-2, CCC, ISO, SRCC, CSA Certificates
3. Delivery time:3-8 days for samples, 5-15days for container
4. Free OEM service
Characteristics
1. It takes advantage of the tap water’s pressure. More pressure more comfortable.
2. The water is heated in short time and meeting your demand for hot water.
3. It can produce more hot water than the general types with continuous hot water coming.
Material
Inner tank: Imported stainless steel (SUS304/2B), 0.4mm thickness
Outer tank: Galvanized steel alloy,0.4mm thickness
Bracket: Galvanized steel alloy, 1.5mm thickness
Heat insulation layer: Imported polyurethane (Bayer, Germany), 50mm thickness
Working temperature: 99 celsius degree
Working pressure: 0.005Mpa (0.05 bars)
Accessory:Optional assistant tank and electrical heater
Warranty: 1 year for electric parts/5 Years for the full system /15 Years for the vacuum tube
Different Model For You
Item No. |
Solar Vacuum Tube |
Absorber Area(m2) |
Tank Capacity |
Loading Qty / sets |
|
pcs |
size / mm |
20GP/40GP/40HQ |
|||
YYJ-R021-18 |
18 |
Φ47 X 1500 |
1.69 |
110L |
58/129/144 |
YYJ-R021-20 |
20 |
Φ47 X 1500 |
1.88 |
130L |
53/118/133 |
YYJ-R021-24 |
24 |
Φ47 X 1500 |
2.26 |
160L |
43/97/108 |
YYJ-R021-30 |
30 |
Φ47 X 1500 |
2.83 |
200L |
35/77/87 |
YYJ-R021-36 |
36 |
Φ47 X 1500 |
3.40 |
250L |
30/68/75 |
|
|
|
|
|
|
YYJ-R022-15 |
15 |
Φ58 X 1800 |
1.97 |
150L |
43/86/100 |
YYJ-R022-18 |
18 |
Φ58 X 1800 |
2.36 |
180L |
39/82/96 |
YYJ-R022-20 |
20 |
Φ58 X 1800 |
2.62 |
200L |
34/72/84 |
YYJ-R022-24 |
24 |
Φ58 X 1800 |
3.15 |
240L |
31/65/77 |
YYJ-R022-30 |
30 |
Φ58 X 1800 |
3.95 |
300L |
22/50/58 |
YYJ-R02-236 |
36 |
Φ58 X 1800 |
4.75 |
360L |
16/40/43 |
It is our standard model, we can costomize it according to your demands(100L-440L)
Remark:
1. Diameter of the tank: 360/460mm
2. Insulation thickness: 50mm
2. Vent connection: 1/2"
4. Electric heater connection: 47mm
5.Cold water inlet: 1/2"
6. Hot water outlet:3/4"
7. Installation angel: 30/45
