Specifications
1.SUS304 Inner tank
2.CCC,CE,ISO
3.delivery:10-15days
4.OEM service
5. Accessory: Optional assistant tank and electrical heater
6.Warranty: 1 year for electric parts/5 Years for the full system /15 Years for the vacuum tube
Characteristics
1. It takes advantage of the tap water’s pressure. More pressure more comfortable.
2. The water is heated in short time and meeting your demand for hot water.
3. It can produce more hot water than the general types with continuous hot water coming.
Material
Inner tank |
Imported stainless steel (SUS304/2B), 0.4mm thickness
|
Outer tank |
Galvanized steel alloy,0.4mm thickness
|
Bracket |
Galvanized steel alloy, 1.5mm thickness
|
Heat insulation layer |
Imported polyurethane (Bayer, Germany), 50mm thickness
|
Working temperature |
99 celsius degree
|
Working pressure |
0.005Mpa (0.05 bars)
|
Working Principle
Different Model For You
Item No. |
Solar Vacuum Tube |
Absorber Area(m2) |
Tank Capacity |
Loading Qty / sets |
|
pcs |
size / mm |
20GP/40GP/40HQ |
|||
YYJ-R021-18 |
18 |
Φ47 X 1500 |
1.69 |
110L |
58/129/144 |
YYJ-R021-20 |
20 |
Φ47 X 1500 |
1.88 |
130L |
53/118/133 |
YYJ-R021-24 |
24 |
Φ47 X 1500 |
2.26 |
160L |
43/97/108 |
YYJ-R021-30 |
30 |
Φ47 X 1500 |
2.83 |
200L |
35/77/87 |
YYJ-R021-36 |
36 |
Φ47 X 1500 |
3.40 |
250L |
30/68/75 |
|
|
|
|
|
|
YYJ-R022-15 |
15 |
Φ58 X 1800 |
1.97 |
150L |
43/86/100 |
YYJ-R022-18 |
18 |
Φ58 X 1800 |
2.36 |
180L |
39/82/96 |
YYJ-R022-20 |
20 |
Φ58 X 1800 |
2.62 |
200L |
34/72/84 |
YYJ-R022-24 |
24 |
Φ58 X 1800 |
3.15 |
240L |
31/65/77 |
YYJ-R022-30 |
30 |
Φ58 X 1800 |
3.95 |
300L |
22/50/58 |
YYJ-R02-236 |
36 |
Φ58 X 1800 |
4.75 |
360L |
16/40/43 |
Remark:
1. Diameter of the tank: 360/460mm
2. Insulation thickness: 50mm
3. Vent connection: 1/2"
4. Electric heater connection: 47mm
5.Cold water inlet: 1/2"
6. Hot water outlet:3/4"
7. Installation angel: 30/45
