Product: 10G XFP BIDI Transceiver telecom equipment
Description:
Baudcom 10G XFP WDM module is compliant with the IEEE803.3ae 10Gbase-Bx. and transmission distance up to 20km on SMF.
The transceiver module comprises a transmitter with a 1270/1330nm DFB laser transmitter, an integrated 1330/1270nm detector preamplifier(IDP) mounted in an optical header and a limiting post-amplifier IC. Transmitter and receiver are separate within a wide temperature range of 0℃ to +70℃ and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
Feature:
Supports 9.95Gb/s to 10.5Gb/s bit rates
¨ Hot-pluggable XFP footprint
¨ Maximum link length of 20km with SMF
¨ 1270/1330nm DFB laser Transmitter and 1330/1270nm Receiver
¨ XFP MSA package with LC connector
¨ No reference clock required
¨ Loop Back Support.
¨ +3.3V,+1.8V power supply
¨ Power dissipation <2W
¨ Compatible with RoHS
¨ Built-in digital diagnostic functions
¨ Temperature range 0°C to 70°C
Applications
¨ 10GBASE-LR at 10.3125Gbps
¨ 10GBASE-LW at 9.953Gbps
¨ 10GBASE-BX 10G Ethernet
¨ 10GBASE-BX 10G Ethernet with FEC
Ordering information
| BDTRX873L1SN-20 | 1270nm DFB laser Transmitter and 1330nm Receiver, 10Gbps,20km,0C~ +70C |
| BDTRX837L1SN-20 | 1330nm DFB laser Transmitter and 1270nm Receiver, 10Gbps,20km,0C~+70C |
10G XFP BIDI Transceiver with LC connector picture:
FAQ
1.How can i get a transceiver sample ?
You need place sample order to us.We will arrange the sample production for you.
2.Could you do design for us?
yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
3.How can we place order?
After we made agreement on the product' parameters, we will make proforma invoice for your confirmation.when we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if you don't have ship forwarder, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
4.How about the shipping for transceiver?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. usually it takes about 7work days to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
6.what's your products' advantages ?
A. good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,assemble,packing and shipping.
D. Aftersale services, if there is quality problem, we will offer you replacement for defective quantity.
Packaging & Shipping
The devices will be well packaged by carton with Foam or other shock proof materials.
Certifications
Factory production
Product testing
After-Sales Service
The goods warranty time is THREE years,we will provide best support by TEL,email,remote control or engineers in field.
Your any questions will be responsed within 12hours!
